S
PECIFICATIONS
Electrical Characteristics
Analog Impedance
Loop Resistance
End-to-End Loss
Ring-Ground Resistance
Channel Signature
Tip-Ring
Tip-Ground
Ring-Ground
Environmental
Operating Elevation
Temperature
Humidity
Physical
Weight
Height
Width
Depth
FLC-704 List 4B
600 Ω
100 Ω, (CO switch to COT) maximum
–2.5 dB ±1.0 dB at 100 Hz
500 Ω
Loop Start Lines
(open)
162 kΩ, 1%
226 kΩ, 1%
–200 ft. to 13,000 ft. (–60 m to 4000 m)
–40° F to +150° F (–40° C to +65° C)
5% to 95% (noncondensing)
0.8 lb. (0.4 kg.)
6.75 in. (17.1 cm.)
1.0 in. (2.5 cm.)
10.5 in. (26.7 cm.)
January 6, 2003
Ground Start Lines
23.75 kΩ, 1%
162 kΩ, 1%
226 kΩ, 1%
