Installing The Flc-706 In The Cot Shelf; Provisioning The Flc-706; Verify Operation; Outgoing Calls - ADC PG-Flex FLC-706 1A Technical Practice

SCP-FLC706-011-03H
I
NSTALLING THE
Insert the FLC-706 into the COT shelf. Ensure the LEDs go through the following sequencing:
•
turn ON for about 2 seconds
•
turn OFF for about 2 seconds
•
scan ON from top to bottom
•
turn OFF
If the LEDs do not follow the above sequence, see

Provisioning the FLC-706

Provision the FLC-706 using a List 3 or higher COLU practice. Access the ISDN Channel Setup menu and select
the appropriate options.

Verify operation

Verify incoming and outgoing calls for both B channels, where B1 is the digitized voice channel and B2 is the
data channel:
When verifying the B1 and B2 channels, only the B channel used for digitized voice has dial tone. The data
channel does not have dial tone.
To verify the operation steps, use a Tektronix Craftec CT-100 ISDN type test set (or equivalent) that can
generate a PRBS/2047 pattern to perform a data Bit Error Rate Test (BERT) when the circuit connects
to the far end. This is the most stressful pattern for ISDN circuits. A test result that does not exceed 10
BER must be demonstrated.

Outgoing calls

Verify outgoing calls for both B channels, for example, calls from the NT1 to the LT (refer to
1 Originate an outgoing B1 voice call and make sure that:
a dial tone is present
b the number you called is displayed (when answered)
the number from which you called is displayed as the originating number
2 Hold up the B1 voice circuit, then switch to the B2 data circuit.
3 Originate an outgoing B2 data call to the data loopback (LPBK) test line and perform the BER test (after the
data call is established).
4 After the B2 data test is completed, drop the B2 data line, then drop the B1 voice line.
5 Return all circuits to normal.
FLC-706 List 1A
FLC-706
IN THE
January 6, 2003
COT S
HELF
Table 2 on page 7.

Installing the FLC-706 in the COT Shelf

Figure 1 on page
-7
2):
5
