Hudson - Table
Assembly Instructions
- Please keep for future reference
331/8218
Dimensions
Width - 183cm
Depth - 92cm
Height - 76cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
Customer Helpline: 03456 400 800
Issue 1 - 10/10/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Hudson 331/8218
Summary of Contents for Argos Hudson 331/8218
- Page 1 Hudson - Table Assembly Instructions - Please keep for future reference 331/8218 Dimensions Width - 183cm Depth - 92cm Height - 76cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800 Issue 1 - 10/10/14...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly Check you have all the This product has been produced We do not components and tools listed on from natural timber; you may recommend the pages 2 and 3. notice some variation in the grain use of power and colour of different component...
- Page 3 Components - Panels Please check you have all the panels listed below 1 Top panel (183 x 92cm) 2 Leg x 2 (82 x 70cm) 3 Cross rail (94 x 9.2cm) 4 Support rail x 2 (88 x 9.2cm)
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 03456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Fixing rail. Fix support rail into the pre drilled holes in the leg using bolts allen key Repeat step 1 for the other leg and support rail. Step 2 Fixing cross rail. Important: Two people are required for an easier assembly.
- Page 6 Assembly Instructions Step 3 Fixing top panel. Important: Two people are required for an easier assembly. Caution: Carefully lay the top panel on a soft and clean surface to avoid damaging the product. Fix legs into the pre drilled holes in the top panel using bolts and allen key...
- Page 7 Hudson - Cross Leg Bench Assembly Instructions - Please keep for future reference 356/4828 Dimensions Width - 170cm Depth - 35cm Height - 45cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800 Issue 1 - 10/10/14...
- Page 8 Safety and Care Advice Important – Please read these instructions fully before starting assembly Check you have all the This product has been produced We do not components and tools listed on from natural timber; you may recommend the pages 2 and 3. notice some variation in the grain use of power and colour of different component...
- Page 9 Components - Panels Please check you have all the panels listed below 1 Seat panel (170 x 35cm) 2 Cross rail (140 x 6.5cm) 4 Support rail (55 x 4.5cm) 5 Vertical frame x 2 (18 x 6.5cm) 3 Leg x 2 (42.5 x 33.8cm)
- Page 10 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 03456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 11 Assembly Instructions Step 1 Fixing vertical frames. Fit vertical frames cross rail as shown, then fix using bolts allen key Step 2 Fixing rail. Fix support rail in the pre drilled holes on vertical frames using screws Step 3 Fixing cross rail. Important: Two people are required for an easier...
- Page 12 Assembly Instructions Step 4 Fixing seat panel. Important: Two people are required for an easier assembly. Fix seat panel into the pre drilled holes in the legs using bolts allen key Step 5 Caution: Carefully lay the seat panel on a soft and clean surface to avoid damaging the product.
