Hartley Glass Dining Table
Assembly Instructions
331/1538
- Please keep for future reference
Dimensions
Width - 160cm
Depth - 90cm
Height - 75cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing part s, call the Customer Helpline:
Argos = 0345 6400800
Issue 1 - 25/10/14
