Murano Bedside Table
Assembly lnstructions - Please keep for future reference
330/8448
Dimensions
Depth- 35 cm
Width - 43 cm
Height - 60 cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800
Issue 1- 02-12-14
Advertisement
Related Manuals for Argos Murano 330/8448
Summary of Contents for Argos Murano 330/8448
- Page 1 Murano Bedside Table Assembly lnstructions - Please keep for future reference 330/8448 Dimensions Depth- 35 cm Width - 43 cm Height - 60 cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800 Issue 1- 02-12-14...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Check you have all the Assemble the item as close We do not components and tools listed on to its final position (in the same recommend the pages 2 and 3.
-
Page 3: Components - Parts
Components - Parts lf you have damaged or missing components. call the Customer Helpline: 0345 6400 800 1 Main body x 2 2 Drawer (27.5 x 33 x 13cm) x 2 (35 x 43 x 60 cm) (Handles pre-assembled inside) - Page 4 Components - Fittings 0345 6400 800 4 x 22 mm Screw x 2 18mm Dia Plastic washer x 2 15 mm Dia Flat washer x 2 Drawer Handle x 2 All pre-assembled inside drawers Tools required Phillips Ruler/tape screwdriver 95 100 105 110 115 120 125 130 135 140 145 150 measure (Not supplied) R uler - Use this ruler to help correctly identify the screws...
- Page 5 Assembly Instructions Attaching handles Pull out the drawer. Remove handles that have been pre-assembled inside the drawers. Inside drawer Re-secure handles to the outside of the drawers using fixings Inside Plastic washers drawer are located in between the mirror front and the handle.
- Page 6 Assembly Instructions If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800 Home Retail Group. 489-499 Avebury Boulevard. Saxon Gate West. Central Milton Keynes. MK9 2NW...
- Page 7 Murano 5 Drawer Chest Assembly lnstructions - Please keep for future reference 332/6138 Dimensions Depth - 50 cm Width - 92 cm Height - 122 cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800 Issue 1- 03-12-14...
- Page 8 Safety and Care Advice Important - Please read these instructions fully before starting assembly Check you have all the Assemble the item as close We do not components and tools listed on to its final position (in the same recommend the pages 2 and 3.
- Page 9 Components - Parts lf you have damaged or missing components. call the Customer Helpline: 0345 6400 800 1 Main body 2 Drawer (72.5 x 39.5 x 18cm) x 10 (50 x 92 x 122 cm) (Handles pre-assembled inside)
- Page 10 Components - Fittings 0345 6400 800 15 mm Dia Flat washer x 10 4 x 22 mm Screw x 10 18mm Dia Plastic washer x 10 Wall strap x 2 7x16mm Screw x 2 Drawer Handle x 10 All pre-assembled inside drawers Tools required Phillips Ruler/tape...
- Page 11 Assembly Instructions Attaching handles Pull out the drawers. Remove handles that have been pre-assembled inside the drawers. Inside drawer Re-secure handles to the outside of the drawers using fixings Inside drawer...
- Page 12 Assembly Instructions Fixing the wall Assemble wall straps to the back of the unit using screws With help, move the unit to the desired location. Mark the fixing hole locations on the wall and remove the unit. Drill the wall and fit suitable plugs for your wall type.
- Page 13 Murano Dressing Table Assembly lnstructions - Please keep for future reference 355/0241 Dimensions Depth - 40 cm Width- 80 cm Height - 75 cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800 Issue 1- 03-12-14...
- Page 14 Safety and Care Advice Important - Please read these instructions fully before starting assembly Check you have all the Assemble the item as close We do not components and tools listed on to its final position (in the same recommend the pages 2 and 3.
- Page 15 Components - Parts lf you have damaged or missing components. call the Customer Helpline: 0345 6400 800 Table top (with drawers) Legs (back) x 2 (80 x 40 x 18 cm) (5.8 x 5.8 x 72 cm) Legs (front) x 2 (5.8 x 5.8 x 72 cm)
- Page 16 Components - Fittings 0345 6400 800 15 mm Dia Flat washer x 2 4 x 22 mm Screw x 2 18mm Dia Plastic washer x 2 Drawer Handle x 2 M8 x 30 mm Allen screw x 8 18 mm Dia Flat washer x 8 Allen key x 1 7x16mm Screw x 2 Wall strap x 2...
- Page 17 Assembly Instructions Preparing top With help, carefully place table top upside down onto a clean flat surface. Warning: The top is heavy and fragile. Lift and handle with care. Remove the 2 drawers from the table top. Assembling legs Carefully locate back legs and front legs in to each corner of table top...
- Page 18 Assembly Instructions Securing legs Secure the legs using fixings Note: Do not overtighten. Remove Inside drawer Re-assemble Inside drawer...
- Page 19 Assembly Instructions Fixing the wall Carefully turn the table over into the standing position. Warning: The table is heavy and fragile. Handle with care. Assemble wall straps the back of the unit using screws With help, move the table to the desired location. Mark the fixing hole locations on the wall and remove the unit.
