2.2 展开至平衡锁定状态
出厂时稳定器主体部分处于收纳锁定状态,请分别将三轴电机锁拨动至解锁位置,调整三轴的位
置至平衡锁定状态,再分别将三轴电机锁拨动至锁定位置,方便下一步操作。
3
2
1
收纳锁定状态
3. 安装相机 / 手机
以安装相机为例。
安装前, 确保相机 已做好拍摄准备 (已安装镜头, 存储卡, 安装电池并确保电量充足, 取下镜头盖) ,
确保已完成"2.
准备工作"的步骤,稳定器处于平衡锁定状态
3.1 安装快装板
将快装板安装至相机底部,拧紧相机固定螺丝。
如相机无内置 1/4-20 英寸螺丝孔位,需置入对应的转接组件,再按以上方式安装。
可选用手机夹具,将手机置入夹具中,再按以上方式安装。
CN
平衡锁定状态
并使稳定器关机或休眠。
,
- 11 -
3.2 安装镜头支架(选装)
可根据需要选择将镜头支架安装固定在快装板,支架软胶顶住镜头,拧紧镜头支架固定旋钮。建
议搭载较长、较重的镜头时安装该支架。
3.3 安装至稳定器
解锁快装版安全锁①,将快装板连同相机,按指示方向卡入安装卡槽②,前后调整相机至大致平
衡后锁紧安全锁①。安装时尽量将相机贴紧俯仰轴,可根据相机宽度,解锁滑块固定锁③,左右
移动滑块调整位置后锁紧固定锁③。
2
!
3
1
3
