Presenting Films and Other Transparent Materials

Films can be placed on the stage for presentation.
3.
1.
Press the [LIGHT] button to turn on
the back illumination
The lighting source changes whenever the [LIGHT] button is
pressed.
illuminations
Back
2.
Place the films and other transparent
illumination
materials on the stage
Place the film at the centre of the stage and adjust the camera
head directly on top of the film.
1.
[LIGHT]
button
3.
Setting Nega/Posi
In the case of a negative film, press the [NEGA/POSI] button to
set to negative mode.
4.
Adjusting zoom
OUT
5.
5.
Adjusting brightness
AUTO
4.
Notes
6.
● Automatic brightness adjustment will be disabled whenever
Nega is selected. The indicator lamp blinks rapidly to indicate
that operation is not possible.
● Under negative mode, pressing the [BRIGHT
the images while pressing the [BRIGHT
the images.
● Under negative mode, pressing the [WHITE BALANCE] but-
tons [RED
nent while pressing the [RED
the red or blue component.
6.
Adjust focus
Use the [FOCUS
Side
Back
illumination
ZOOM
Adjust such that the portion of the object to
be captured occupies the full screen.
IN
Adjust the brightness while looking at the
BRIGHT
image displayed on the monitor.
] or [BLUE
] decreases the red or blue compo-
] or [BLUE
,
] buttons to adjust the focus.
All
illuminations off
] button dims
] button brightens
] button increases
E-15
