- Page 1 VAL-2012-BBK Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm Specifications and product details subject to change without notice. © Copyright 2022, VOLT Lighting, Lutz FL USA 33549 • All rights ® reserved. customersupport@voltlighting.com • 813.978.3700 - 1 -...
- Page 2 INSTALLATION INSTRUCTIONS VOLT Brass Lanai Light ® VAL-2012-BBK Important: Please Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
- Page 3 Package Contents A. (1) Fixture C. (3) Wall Anchors B. (3) Screws Parts Required (Sold Separately) A. (1) MR11 Bulb Product Dimensions 1.62” 1.62” 10” 3.27” 1.85” customersupport@voltlighting.com • 813.978.3700 - 3 -...
- Page 4 INSTALLATION INSTRUCTIONS VOLT Brass Lanai Light ® VAL-2012-BBK Remove Lens from Fixture Remove the lens from the fixture body by rotating the lens counter-clockwise. Lens Fixture Body Install Fixture Body Place the fixture wires through the cut out of the backplate.
- Page 5 Install MR11 Bulb Insert the MR11 bulb with MR11 Bulb the correct wattage and type marked on the fixture label. CAUTION: Do not exceed Socket maximum wattage marked on luminaire label. Install Lens Install the lens to the fixture body by rotating clockwise. Lens Fixture Body customersupport@voltlighting.com •...
- Page 6 INSTALLATION INSTRUCTIONS VOLT Brass Lanai Light ® VAL-2012-BBK Wire Connections Main Supply Cable Fixture Wires Wire Connectors Strip both leads from the fixture wires. Using two UL listed wire connectors (sold separately), connect the leads from the fixture wires to the main supply cable leads.
