INSTALLATION INSTRUCTIONS
VOLT
Low Voltage Landscape Lighting
®
VOLT
Top Dog with Integrated Hub Top
®
VAL-2100-0-BBZ (includes part# VAL-180-X-BXX & VAC-ZWM7-BBZ)
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
Specifications and product details subject to change without notice.
© Copyright 2019, VOLT
customersupport@voltlighting.com • 813.978.3700
Lighting, Lutz FL USA 33549 • All rights reserved.
®
- 1 -
Advertisement
Table of Contents
Related Manuals for Volt VAL-2100-0-BBZ
Summary of Contents for Volt VAL-2100-0-BBZ
- Page 1 ® VOLT Top Dog with Integrated Hub Top ® VAL-2100-0-BBZ (includes part# VAL-180-X-BXX & VAC-ZWM7-BBZ) Help Hotline: 1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST) Specifications and product details subject to change without notice. © Copyright 2019, VOLT Lighting, Lutz FL USA 33549 •...
-
Page 2: Important Safety Instructions
VOLT Top Dog with Integrated Hub Top ® VAL-2100-0-BBZ (includes part# VAL-180-X-BXX & VAC-ZWM7-BBZ) Important: Please Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty. -
Page 3: Package Contents
Package Contents A. (1) Fixture Body Product Dimensions 2.5” There are three types of mounts that are sold separately for this fixture; the Stake Mount, Surface Mount and Tripod Mount. customersupport@voltlighting.com • 813.978.3700 - 3 -... - Page 4 INSTALLATION INSTRUCTIONS VOLT Top Dog with Integrated Hub Top ® VAL-2100-0-BBZ (includes part# VAL-180-X-BXX & VAC-ZWM7-BBZ) Option1: Stake Mount Wire Connection Connectors Integrated Hub Top Fixture Wires Main Supply Wires Stake Mount Main Supply Wire Main Supply Wire Continuation Insert the main supply wire continuation (if needed) and the main supply wire up through the bottom of the stake mount and strip the ends of both sets of supply wires.
- Page 5 Install Stake Mount Clear away an area in the ground at the wireway slot on top of the stake. Lay the supply wires Stake Mount into the wireway slot and screw Wireway Slot the stake mount on to the stake. Tighten until snug.
- Page 6 INSTALLATION INSTRUCTIONS VOLT Top Dog with Integrated Hub Top ® VAL-2100-0-BBZ (includes part# VAL-180-X-BXX & VAC-ZWM7-BBZ) Option 2: Surface Mount Wire Connection Connectors Integrated Hub Top Fixture Wires Main Supply Wires Surface Mount Main Supply Wire Main Supply Wire Continuation...
-
Page 7: Option 3: Tripod Mount
Option 3: Tripod Mount Wire Connection Connectors Integrated Hub Top Fixture Wires Main Supply Wires Tripod Mount Main Supply Wire Main Supply Wire Continuation Insert the main supply wire continuation (if needed) and the main supply wire up through the bottom of the tripod mount and strip the ends of both sets of supply wires. -
Page 8: Bulb Installation
INSTALLATION INSTRUCTIONS VOLT Top Dog with Integrated Hub Top ® VAL-2100-0-BBZ (includes part# VAL-180-X-BXX & VAC-ZWM7-BBZ) Bulb Installation Remove Glare Guard and Lens Loosen the lens and the set screw and remove the glare Glare Guard guard. Set Screw Lens... - Page 9 Install Lens and Glare Guard Thread the lens onto the fixture body and hand tighten. Then, place the glare guard onto Glare Guard the lens and secure with the previously removed set screw. Set Screw Lens Fixture Body customersupport@voltlighting.com • 813.978.3700 - 9 -...
- Page 10 VOLT Top Dog with Integrated Hub Top ® VAL-2100-0-BBZ (includes part# VAL-180-X-BXX & VAC-ZWM7-BBZ) Install/Replace Bulb Loosen the set screw to remove the glare guard and the lens to expose the bulb. Replace it with the correct wattage and type marked on the fixture label.
- Page 11 customersupport@voltlighting.com • 813.978.3700 - 11 -...
- Page 12 . v o l t l i g h t i n g . c o m Specifications and product details subject to change without notice. © Copyright 2019, VOLT Lighting, Lutz FL USA 33549 • All rights reserved.
