- Page 1 STORM COMMANDER ® OWNER’S MANUAL Product Code: CEC056 Version 1.1 Copyright © Enduraplas. All Rights Reserved.
-
Page 2: Table Of Contents
English CONTENTS INTRODUCTION OVERVIEW OVERVIEW DESCRIPTION WARNINGS GETTING STARTED 7 - 15 MAINTAINING TROUBLESHOOTING WARRANTY 18 - 21 Storm Commander ®... -
Page 3: Introduction
English INTRODUCTION Congratulations! You now own a Camion™ Storm ® Commander Take a look through this owner’s manual to learn how the ® pros use their Camion™ Storm Commander controller. Version 1.1... -
Page 4: Overview
English OVERVIEW Storm Commander ®... -
Page 5: Overview Description
English OVERVIEW DESCRIPTION 1. Synced Indicator Light (Red-not connected, Green connected). 2. Target Rate Indicator, Shift/Site Totals. 3. Actual Rate Gallons per Acre (GPA)/Volume. 4. Geofence Location, gallons used/left, GPS speed. 5. Auxilary 1 (work light). 6. Left spray toggle switch. 7. -
Page 6: Warnings
English WARNINGS 1. Always make sure controller is in a safe place in the vehicle and is secured in a location where it does not obstruct view of surroundings. 2. Always pay attention when operating the controller when vehicle is moving. 3. -
Page 7: Getting Started
English GETTING STARTED Storm Commander Setup 1) Turn on vehicle key to power up the ® RV plug so your Storm Commander has power. 2) To power up the receiver box at the back of unit, plug the RV socket into the 7 pin plug on back of truck. - Page 8 English GETTING STARTED Storm Commander Setup ® 5) Hook up Storm Commander control box arm to back of controller and install controller mount into the cupholder of the vehicle cab. Important Tip: The control unit in the cab needs an unobstructed view to GPS signal and shouldn’t be covered or shielded with objects.
- Page 9 English GETTING STARTED Pairing Storm Commander with Unit 1) Press the power button on the top right corner of the controller to power up. 2) Press and hold settings button on the top right corner of the screen for a couple seconds or until it activates a long beep.
- Page 10 English GETTING STARTED Pairing Storm Commander with Unit 5) Press ‘Resync’ button - your controller will pair with the receiver box on the sprayer. Controller display will now show ID numbers above resync button. 6) X out of the screen by hitting the top right-hand corner of the screen.
- Page 11 English GETTING STARTED Confirming Controller is Synced to Unit 1) Turn the main boom activation toggle switch on to activate spray control. 2) Press the A/M button to activate ‘Manual’ mode allowing you to test valves are operating. 3) Turn ‘Left’, ‘Center’, and ‘Right’ toggle switches on to verify the unit is connect- ed and then turn back off to close the valves.
- Page 12 English GETTING STARTED Filling Unit with Liquid 1) Before filling your unit with liquid, press the tank fill button near the bottom right of the controller screen. Then fill your sprayer tank with liquid. 2) Once the tank is filled, key in the total gallons in your tank and hit confirm.
- Page 13 English GETTING STARTED Getting Ready to Spray 1) Set your target spray rate by simply pressing the up and down arrow keys. This will change rate in 5 gallon increments. Set your desired gallon per acre (GPA) rate. 2) Ensure your pump motor is powered on and running.
- Page 14 English GETTING STARTED Resetting Shift/Site Settings. 1) The Shift/Site total alternates on screen. To get to ‘shift total’, wait until display shows ‘shift total’, then press the shift icon. To get to ‘site total’, wait until display shows ‘site total’, then press the site icon.
- Page 15 English GETTING STARTED Add-On Option 1) If your unit has an auxilary work light, turn your toggle switch on at the work light. This switch is located directly be- low the work light. 2) To turn on you auxiliary work light from the controller, ensure the toggle switch in step 1 is on, then press the AUX 1 button on the bottom left of the...
-
Page 16: Maintaining
English MAINTAINING Keeping your Storm Commander controller in good condition will help you lengthen the life of the components. Everyone knows a well maintained piece of equipment ensures a longer life span. Watch Instruction Videos: www.youtube.com Discover More Helpful Tips: www.IceControlTraining.com Storm Commander ®... -
Page 17: Troubleshooting
English TROUBLESHOOTING CONDITION CAUSE REMEDY Unit not Power supply. 1. Ensure your unit is powering on. plugged in. 2. Make sure cable is connected properly. 3. Make sure vehicle key is on and there is power at the plug socket. Insufficient flow 1. -
Page 18: Warranty
English WARRANTY LIMITED WARRANTY 1. Poly Tank Limited Warranty - Subject to other terms in this Limited Warranty, Manufacturer warrants to the original end user that this Tank will be free from material defects caused during the manufacturing process for a period of 5 years from the Purchase Date provided such warranty to the original end user shall be extended to 10 years from the Purchase Date if the original end user registers the Tank with Manufacturer within 30 days of the... - Page 19 English 3. Limitation of Liability under the Limited Warranty - In addition to those warranties disclaimed and excluded in clause 2 above, Manufacturer expressly further limits its warranty and liability under the Limited Warranty as set forth below in this clause 3. 3.1.
- Page 20 English 3.2. Without limiting the generality of clause 3.1: Manufacturer will not be liable for any personal injury, indirect or incidental damages, consequential losses, loss of liquids, loss of profit or any like claims whatsoever arising from any use of, or incidental to, or repairs to any of the Goods by a party other than Manufacturer;...
- Page 21 English 5. Claims and Questions - If you have questions about this Limited Warranty or to make a warranty claim, contact Manufacturer at: customercare@enduraplas.com 6. Definitions - For this Limited Warranty the following definitions apply: Manufacturer means Enduraplas LLC. Purchase Date means the date upon which the applicable goods were purchased by the original end user.
- Page 22 ® CAMION by Enduraplas 1 (877) 265-9929 cs@camionsystems.com www.camionsystems.com 113 1st Street, Neche ND 58265, USA A Brand By Enduraplas Discover More Helpful Tips: www.IceControlTraining.com Copyright © Enduraplas. All Rights Reserved.
