ICE MASTER T-SERIES
IMT250
IMT250E
IMT250ESC
IMT250G
IMT250GSC
IMT1200, IMT1600, IMT1900, IMT2500, IMT3000
Version 1.6
OWNER'S MANUAL
IMS500T-ECOMAXGPS 2022
Product Codes:
IMT300
IMT500
IMT300E
IMT500E
IMT300ESC
IMT500ESC
IMT300G
IMT500G
IMT300GSC
IMT500GSC
Copyright © Enduraplas. All Rights Reserved.
®
IMT800
IMT800E
IMT800ESC
IMT800G
IMT800GSC
IMT1000
IMT1000E
IMT1000ESC
IMT1000G
IMT1000GSC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICE MASTER T Series and is the answer not in the manual?

Questions and answers

Patrick Moore
April 11, 2025

Where can I buy a 16 guage IM 3-toggle switch controller for ice master t-series?

0

Subscribe to Our Youtube Channel

Related Manuals for CAMION ICE MASTER T Series

Summary of Contents for CAMION ICE MASTER T Series

  • Page 1 ICE MASTER T-SERIES ® OWNER’S MANUAL IMS500T-ECOMAXGPS 2022 Product Codes: IMT250 IMT300 IMT500 IMT800 IMT1000 IMT250E IMT300E IMT500E IMT800E IMT1000E IMT250ESC IMT300ESC IMT500ESC IMT800ESC IMT1000ESC IMT250G IMT300G IMT500G IMT800G IMT1000G IMT250GSC IMT300GSC IMT500GSC IMT800GSC IMT1000GSC IMT1200, IMT1600, IMT1900, IMT2500, IMT3000 Version 1.6 Copyright ©...

  • Page 2: Table Of Contents

    English CONTENTS INTRODUCTION WARNINGS 4 & 5 GETTING STARTED 6 - 17 CALIBRATING 18 & 19 MAINTAINING 20 & 21 TROUBLESHOOTING 22 & 23 WARRANTY 24 - 27 PARTS BREAKDOWNS - ICE MASTER ® 28 - 70 T-SERIES Ice Master T-Series ®...

  • Page 3: Introduction

    English INTRODUCTION Congratulations! You now own a Camion™ sprayer. Durable design and construction assure you a lifetime of extreme performance. No sprayer is tougher. No sprayer will last longer. Take a look through this owner’s manual to learn how the pros use their Camion™...

  • Page 4: Warnings ! 4

    English WARNINGS 1. Do not exceed vehicle manufacturers loading, towing or lifting specifications and regulations. 2. Ensure tank is firmly secured in an appropriate manner. 3. Use caution at all times, particularly when driving on rough terrain. 4. Comply with chemical manufacturers safety requirements and all relevant legislations.
  • Page 5 English 13. No modifications and/or alterations may be made to this sprayer. Any such modifications not only void the sprayer warranty but can make the unit dangerous to anyone operating the pump. 14. Always inspect hoses and piping to avoid burst injuries. 15.

  • Page 6: Getting Started

    English GETTING STARTED Setting Up Your Sprayer 1) The two openings at the front of the frame allow you to move the unit using fork points. 2) When loading your sprayer, we recommend you place blocking between your sprayer and the front of the bed of your truck.
  • Page 7 English GETTING STARTED Setting Up Your Sprayer 4) If you ordered the hose reel option, screw the hose reel handle into place. 5) If you purchased a receiver hitch mount option with your unit, insert the four bolts through the receiver hitch, then through the boom plate.
  • Page 8 English GETTING STARTED Setting Up Your Sprayer 8) To install your boom to the brackets, loosen the carriage bolts on the boom (leaving nuts and washers on bolts). Align carriage bolts with quick attach brackets and slide them into the bracket slots, then lower the boom down to desired height.
  • Page 9 English GETTING STARTED Setting Up Your Sprayer 12) If you purchased a unit with our high flow electric Ecomax® pump option, you will need to hook up the ring terminals on the wire harness to your battery and route the wire harness back to the elec- tric motor.
  • Page 10 English GETTING STARTED Setting Up Your Sprayer 14) Then route the in cab power switch cable into your vehicle cab and connect it to the on/off switch. 15) If you purchased a hydraulic unit, hook up your desired hydraulic hoses to the side ports on the hydraulic pump.
  • Page 11 English GETTING STARTED Setting Up Your Sprayer 18) If you have a gas powered unit, you will need to install a battery into the provided battery box and connect your positive and negative cables to the correct terminals. Hooking Up Standard Controls 1) If your applicator does not have a GPS flow control option, you will need to connect the standard control wire...
  • Page 12 English GETTING STARTED Hooking Up GPS Flow Control 4) Connect the cup holder mount to the Storm Commander® controller. 5) Install the Storm Commander® controller in your cab and connect it to the 12V plug. 6) Route the power cable (to prevent any pinching or damage) from the Storm Commander®...
  • Page 13 English GETTING STARTED Operating Your Sprayer 1) You will need to prime the pump before using it. Start by filling the tank at least a quarter full of water. 2) Then open the suction valve between the tank and the pump. 3) Place the 3-way valve in recirculation position to allow liquid to recirculate back to the tank.
  • Page 14 English GETTING STARTED Operating Your Sprayer 4) If your applicator has the gas engine driven pump, open the top cap of the pump, and fill the pump with water. Before starting the engine make sure both the drain plug and prime plug are tightened securely to properly hold the sealing O-rings in place.
  • Page 15 English GETTING STARTED Operating Your Sprayer 8) To fill the applicator, close the suction valve between the tank and the pump. 9) Make sure the 3-way valve on top of pump is in recirculation position, then connect storage source hose to your applicator and open the external fill valve.
  • Page 16 English GETTING STARTED Operating Your Sprayer 11) To use the spray gun, ensure the 3-way valve on top of pump is in closed position and hose reel shutoff valve is in the open position. Important Tip: If you are using your hand wand for extended periods of time, it is best to leave the 3-way valve, on top of pump, slightly open to allow liquid to recirculate through the pump even when the hand gun is not in use.
  • Page 17 English GETTING STARTED Operating Your Sprayer 14) If you ordered a storage stand, you can attach the legs with the supplied pins. 15) If you purchased the self-loading leg stand, adjust legs to desired height. Ice Master T-Series ®...

  • Page 18: Calibrating 18

    English CALIBRATING Note: Always double check your application rates. The rate/acre listed is only based off the center section (not the two side nozzles) Ice Master T-Series ®...
  • Page 19 English GPM = Gallons Per Minute GPA = Gallons Per Acre GAL/1000 FT = Gallons Per 1000 Square Feet W = Nozzle spacing Gallons Per Minute Formula: GPA x MPH x W (per nozzle) 5,940 Gallons Per Minute Formula: GAL/1000FT x MPH x W (per nozzle) Gallons Per Acre Formula: 5,940 x GPM (per nozzle) MPH x W...

  • Page 20: Maintaining 20

    English MAINTAINING Keeping your sprayer in good condition will help you lengthen the life of the sprayer. Everyone knows a well maintained piece of equipment ensures a longer life span. Sprayer maintenance can seem a huge task if you don’t have the right tools.
  • Page 21 English If required If damaged Every 250 operating hours o once a year After the first 5 operating hours Weekly or every 40 operating hours At the end of work and/or daily Before starting work Version 1.6...

  • Page 22: Troubleshooting 22

    English TROUBLESHOOTING CONDITION CAUSE REMEDY Pump will not 1) Air leak on suction 1) Tighten/replace prime plumbing fittings & hose 2) Blocked/Restricted clamps. Verify suction intake hose hoses are in good 3) Filter cap condition disengaged 2) Remove blockage 3) Filter gasket from suction line, damaged/missing ensure line is not...
  • Page 23 English CONDITION CAUSE REMEDY Pressure gauge 1) Plugged with debris 1) Un-thread, check not registering and clean pressure gauge Hand gun loses 1) Debris in hose or 1) Un-thread nozzle pressure nozzle tip and clean 2) Pump losing prime 2) See Remedy for 3) Pump pressure ‘Pump will not prime dropping/fluctuating...

  • Page 24: Warranty

    English WARRANTY LIMITED WARRANTY 1. Poly Tank Limited Warranty - Subject to other terms in this Limited Warranty, Manufacturer warrants to the original end user that this Tank will be free from material defects caused during the manufacturing process for a period of 5 years from the Purchase Date provided such warranty to the original end user shall be extended to 10 years from the Purchase Date if the original end user registers the Tank with Manufacturer within 30 days of the...
  • Page 25 English 3. Limitation of Liability under the Limited Warranty - In addition to those warranties disclaimed and excluded in clause 2 above, Manufacturer expressly further limits its warranty and liability under the Limited Warranty as set forth below in this clause 3. 3.1.
  • Page 26 English 3.2. Without limiting the generality of clause 3.1: Manufacturer will not be liable for any personal injury, indirect or incidental damages, consequential losses, loss of liquids, loss of profit or any like claims whatsoever arising from any use of, or incidental to, or repairs to any of the Goods by a party other than Manufacturer;...
  • Page 27 English 5. Claims and Questions - If you have questions about this Limited Warranty or to make a warranty claim, contact Manufacturer at: customercare@enduraplas.com 6. Definitions - For this Limited Warranty the following definitions apply: Manufacturer means Enduraplas LLC. Purchase Date means the date upon which the applicable goods were purchased by the original end user.

  • Page 28: Parts Breakdowns - Ice Master

    PARTS BREAKDOWN CONTENTS T-SERIES OVERVIEW 30 - 31 ECOMAX® NON-GPS 32 - 37 ECOMAX® GPS 38 - 43 GAS NON-GPS 44 - 49 GAS GPS 50 - 55 HYDRAULIC GPS 56 - 61 HYDRAULIC NON-GPS 62 - 67 T-SERIES BOOM 68 - 70 DEICING HOSE REEL Ice Master...

  • Page 29: T-Series Overview

    OVERVIEW Hosereel (Optional) T-SERIES ECOMAX NON GPS PLUMBING 2022 View A Version 1.6...
  • Page 30 OVERVIEW DETAIL View A ITEM NO. Part # DESCRIPTION QTY. THD00500OE-NF 500 Gal Sump Bot Tank AVB355 STBBS35 Lg Baffle Ball CFLP16HV 16 inch Hypro Lid Hinged AZFPM0500SS 500 Gallon Pro Master™ Frame - 304 Stainless Steel CBTF200 2 Poly Tank Flange Assembly CBHB20090 2"...

  • Page 31: Ecomax Non Gps

    ECOMAX NON GPS T-SERIES ECOMAX NON GPS PLUMBING 2022 Version 1.6...
  • Page 32 ECOMAX NON GPS View C View B View C View B View A View A VIEW A View A View A Ice Master T-Series ®...
  • Page 33 VIEW B View B Version 1.6...
  • Page 34 VIEW C View C Ice Master T-Series ®...
  • Page 35 PARTS LIST ITEM NO. Part # DESCRIPTION QTY. CBMLS2216 MLS222 Y-Strainer 16 Mesh CBM220TEE 2 Manifold Tee - 220 Series CBMVSF220FP 2-in FP Manifold x 2-in Male Adaptor CB200CAP 2-in Cap CBMV220BLSH 2” FP Bot Load Manifold Valve w/ SH Handle CBM100A 1"...
  • Page 36 PARTS LIST ITEM NO. Part # DESCRIPTION QTY. CBM100MPTSS 1 IN FP Flange x 1 IN Male Thread CSLC432 12V Heavy Duty Pump Plate ACPC03 EcoMax Pump Cover CHWSF033 3/8 SS Flat washer CHBS030423 3/8 x 3/4 Stainless bolt CHBS020523 5-16 x 1 Bolt Stainless Steel CHWSL023 5-16 SS Lock Washer...

  • Page 37: Ecomax Gps

    ECOMAX GPS T-SERIES ECOMAX GPS PLUMBING 2022 Version 1.6...
  • Page 38 DETAIL VIEW View C View B View A VIEW A View A Ice Master T-Series ®...
  • Page 39 VIEW B View B Version 1.6...
  • Page 40 VIEW C View C Ice Master T-Series ®...
  • Page 41 CSLC723 MTS Controller Valve Bracket CBMEVXR2W220A 2 IN Bolted Full Port Reg Valve w3pin WP Con AVTC06 MTS CAMION GPS Junction Box CBMVS220CF 2-in Full Port Stubby Manifold Valve CBM220ASWP90 2 inch Full Port Flange x Hose Shank Sweep Version 1.6...
  • Page 42 PARTS LIST ITEM NO. Part # DESCRIPTION QTY. CB200C90 90 Female coupling to hose shank CBV25271 90 degree Mounting Bracket CBMEVX103A 3-bank electric Banjo Valve bolted with pin con CHUS031234002 1.75 SS U-Bolt APAMT001 12V IMS Ecomax pump CBM100MPTSS 1 IN FP Flange x 1 IN Male Thread CSLC432 12V Heavy Duty Pump Plate ACPC03...

  • Page 43: Gas Non-Gps

    GAS NON GPS T-SERIES GAS NON GPS PLUMBING 2022 Version 1.6...
  • Page 44 DETAIL VIEW View C View B View A VIEW A View A Ice Master T-Series ®...
  • Page 45 VIEW B View B Version 1.6...
  • Page 46 VIEW C View C Ice Master T-Series ®...
  • Page 47 PARTS LIST ITEM NO. Part # DESCRIPTION QTY. 2 inch Poly Pump with 5.5HP Honda Engine Electric CB200PH5E Start CBM220MPT 2-in FP Manifold x 2-in Male Thread CBMLS2216 MLS222 Y-Strainer 16 Mesh CBM220TEE 2 Manifold Tee - 220 Series CBMVSF220FP 2-in FP Manifold x 2-in Male Adaptor CB200CAP 2-in Cap...
  • Page 48 PARTS LIST ITEM NO. Part # DESCRIPTION QTY. CHUS031234002 1.75 SS U-Bolt CTEW018 Battery Terminal - Standard Lug Plated CTEW017 Battery Cable - 4GA. Black CTEW016 Battery Cable - 4GA. Red CTEW037 Battery Box, Polypropylene, for U1 Battery Size Ice Master T-Series ®...

  • Page 49: Gas Gps

    GAS GPS T-SERIES GAS GPS PLUMBING 2022 Version 1.6...
  • Page 50 OVERVIEW View C View B View A VIEW A View A Ice Master T-Series ®...
  • Page 51 VIEW B View B Version 1.6...
  • Page 52 VIEW C View C Ice Master T-Series ®...
  • Page 53 .5 IN FPT x .5 IN MPT Ball Valve CBHB05090 1/2 MNPT x 1/2 Hose Shank 90 CLUESB020002 1/2" hose (to hose reel) CSLC723 MTS Controller Valve Bracket CBMEVXR2W220A 2 IN Bolted Full Port Reg Valve w3pin WP Con AVTC06 MTS CAMION GPS Junction Box Version 1.6...
  • Page 54 PARTS LIST ITEM NO. Part # DESCRIPTION QTY. CBMVS220CF 2-in Full Port Stubby Manifold Valve CBM220ASWP90 2 inch Full Port Flange x Hose Shank Sweep CB200C90 90 Female coupling to hose shank CBV25271 90 degree Mounting Bracket CBMEVX103A 3-bank electric Banjo Valve bolted with pin con CHUS031234002 1.75 SS U-Bolt CTEW018...

  • Page 55: Hydraulic Gps

    HYDRAULIC GPS HYDRAULIC GPS PLUMBING 2022 Version 1.6...
  • Page 56 OVERVIEW View B View C View VIEW A View A B C A Ice Master T-Series ®...
  • Page 57 VIEW B View B Version 1.6...
  • Page 58 VIEW C View C Ice Master T-Series ®...
  • Page 59 PARTS LIST ITEM NO. Part # DESCRIPTION QTY. APDC09HS SS Hydraulic pump CBM220MPT 2-in FP Manifold x 2-in Male Thread CBMLS2216 MLS222 Y-Strainer 16 Mesh CBM220TEE 2 Manifold Tee - 220 Series CBMVSF220FP 2-in FP Manifold x 2-in Male Adaptor CB200CAP 2-in Cap CBMV220BLSH...
  • Page 60 1/2" Nylock Nut 304 SS CHWSF053 1/2 SS flat washer CA46221A58787 Electro-Magnetic Flowmeter with 2 inch Full Port CSLC723 MTS Controller Valve Bracket CBMEVXR2W220A 2 IN Bolted Full Port Reg Valve w3pin WP Con AVTC06 MTS CAMION GPS Junction Box Ice Master T-Series ®...

  • Page 61: Hydraulic Non-Gps

    HYDRAULIC NON GPS HYDRAULIC NON GPS PLUMBING 2022 Version 1.6...
  • Page 62 OVERVIEW View B View C View VIEW A View A B C A Ice Master T-Series ®...
  • Page 63 VIEW B View B Version 1.6...
  • Page 64 VIEW C View C Ice Master T-Series ®...
  • Page 65 English PARTS LIST ITEM NO. Part # DESCRIPTION QTY. APDC09HS SS Hydraulic pump CBM220MPT 2-in FP Manifold x 2-in Male Thread CBMLS2216 MLS222 Y-Strainer 16 Mesh CBM220TEE 2 Manifold Tee - 220 Series CBMVSF220FP 2-in FP Manifold x 2-in Male Adaptor CB200CAP 2-in Cap CBMV220BLSH...
  • Page 66 English PARTS LIST ITEM NO. Part # DESCRIPTION QTY. CHWSF053 1/2 SS flat washer CBM220CPG6 2 x 2 Full Port Flange x 6" CEWCIM03 16 GA IM Wire Harness-3 toggle switch Version 1.6...

  • Page 67: T-Series Boom

    English 12 NOZZLE BOOM IMSB12 12 NOZZLE BOOM Version 1.6...
  • Page 68 English DETAIL OVERVIEW Version 1.6...
  • Page 69 English PARTS LIST ITEM NO. Part # DESCRIPTION QTY. AZFPM006 8 Nozzle Deicing Boom Bracket AMICS002 Poly Shroud For Deicing Boom AZFPM020 1" x 17-3/4" Poly Pipe For Deicing Boom AZFPM018 1" x 12-9/16" Poly Pipe For Deicing Boom AZFPM019 1"...

  • Page 70: Deicing Hose Reel

    CFRH03C PHENOIC TAPERED HANDLE CHWZF105 1 SAE Flat Washer English CFBW04M04FB .5 M BSP - .5 F NPT Heavy Duty Swivel CFPS02M02B 1-2 MPT x 1-2 Hose Barb DEICING HOSE REEL CLUESB020002 1/2 EPDM HOSE - 50" AZKH0018 Lock for Small Hose Reel AZKH0003SS 3ASR03B HR FRAME 304 SS AZKH0003...
  • Page 71 English ACTIVATE YOUR 10-YEAR WARRANTY How to Activate To double your 5-year tank warranty, visit www.camionsystems.com/warranty/ and register this product. Watch Instruction Videos: www.youtube.com Discover More Helpful Tips: www.IceControlTraining.com Ice Master T-Series ®...
  • Page 72 ® CAMION by Enduraplas 1 (877) 265-9929 cs@camionsystems.com www.camionsystems.com 113 1st Street, Neche ND 58265, USA A Brand By Enduraplas Discover More Helpful Tips: www.IceControlTraining.com Copyright © Enduraplas. All Rights Reserved.
