BRINE MASTER 3000

OWNER'S MANUAL

Product Code:

IMSBM3000

Version 1.2

Table of Contents

Need help?

Do you have a question about the BRINE MASTER 3000 and is the answer not in the manual?

Questions and answers

Summary of Contents for CAMION BRINE MASTER 3000

Page 2: Table Of Contents
English CONTENTS INTRODUCTION WARNINGS 4 - 5 GETTING STARTED 6 - 7 OPERATION 8 - 11 MAINTAINING 12 - 14 TROUBLESHOOTING WARRANTY 16 - 19 PARTS BREAKDOWNS 20 - 26 Brine Master ®...
Page 3: Introduction
English INTRODUCTION Congratulations! You now own a Camion™ Brine Master®. Durable design and construction assure you a lifetime of extreme performance. Take a look through this owner’s manual to learn how the pros use their Camion™ Brine Master®. Watch Instruction Videos: www.youtube.com...
Page 4: Warnings
English WARNINGS 1. To ensure your own safety and that of others, you must comply with all relevant environmental, work place health, safety legislation and codes of practice. 2. Select and wear appropriate Personal Protection Equipment in accordance with the label of the product you intend to use.
Page 5 English Discover More Helpful Tips: www.IceControlTraining.com Version 1.2...
Page 6: Getting Started
English GETTING STARTED Electrical Requirements This Brine Master 3000® requires a 230 volt, 30 amp circuit to operate. This product comes pre-wired and has a plug for easy setup. Follow all local code requirements. Use a certified electrician to install power supply.
Page 7 English GETTING STARTED Positioning & Leveling It’s important to make sure the Brine Master® is positioned to allow easy access to fresh water supply and storage tank hook ups at the control station and that it’s level before use. If you are working with an uneven surface, place shimming material under each end and in the middle of the stainless- steel base frame on either side to level the machine.
Page 8: Operation
English OPERATION Startup 1) Connect fresh water supply hose to the “Fresh Water” port valve (#4), and the brine to storage tank hose to the “Discharge” port (#5) and plug the power cord into the power source. 2) Place discharge valve (#1) to “Discharge to Brining Hopper”...
Page 9 English OPERATION Initial Filling 5) Open the “Fresh Water” port valve (#4) and power on the pump, to continue filling the system with fresh water until the orange brine batch tank is filled to the 600 gallon mark. Reference the site gauge tube.
Page 10 English OPERATION Unloading 7) Once the salinity reader indi- cates the brine is at 23.0%, move the discharge valve (#1) to “Dis- charge to Storage” position. Make sure the valve to the left of the flow meter (#6) is in the down position. Important Tip: Perfect brine is 23.3%.
Page 11 English OPERATION Filling 9) Once the brine batch tank is empty, move the suction valve (#2) to “Suction from Fresh Water” position. Continue filling the system with fresh water until the orange brine batch tank is filled to the 600 gallon mark. Reference the site gauge tube.
Page 12: Maintaining
English MAINTAINING Always Clean unit with fresh water at the end of every season to clean out all brine left in brine maker to ensure proper operations for the following years. The unit requires proper care for longevity and proper operation. Follow all requirements for pump and motor by reviewing their manuals that are included.
Page 13 English MAINTAINING As required If damaged When no immediate scheduled use At the end of work and/or daily Before starting work Instruction Ref. Version 1.2...
Page 14 English MAINTAINING Instruction References 14.1 - To clean your refractometer, turn the 5/16” push to connect valves to the off position. Then pull the pin on the front and twist the body of the refractometer counter clockwise to remove it. Clean the lens and the inside body removing any debris.
Page 15: Troubleshooting
English TROUBLESHOOTING CONDITION REMEDY Reduced flow rate 1) Check for a blockage in the filter screen. Hopper is backing up 1) Ensure there is no blockage on or overflowing internal hopper screen. 2) Clean debris or salt away from the screen.
Page 16: Warranty
English WARRANTY LIMITED WARRANTY 1. Poly Tank Limited Warranty - Subject to other terms in this Limited Warranty, Manufacturer warrants to the original end user that this Tank will be free from material defects caused during the manufacturing process for a period of 5 years from the Purchase Date provided such warranty to the original end user shall be extended to 10 years from the Purchase Date if the original end user registers the Tank with Manufacturer within 30 days of the...
Page 17 English 3. Limitation of Liability under the Limited Warranty - In addition to those warranties disclaimed and excluded in clause 2 above, Manufacturer expressly further limits its warranty and liability under the Limited Warranty as set forth below in this clause 3. 3.1.
Page 18 English 3.2. Without limiting the generality of clause 3.1: Manufacturer will not be liable for any personal injury, indirect or incidental damages, consequential losses, loss of liquids, loss of profit or any like claims whatsoever arising from any use of, or incidental to, or repairs to any of the Goods by a party other than Manufacturer;...
Page 19 English 5. Claims and Questions - If you have questions about this Limited Warranty or to make a warranty claim, contact Manufacturer at: customercare@enduraplas.com 6. Definitions - For this Limited Warranty the following definitions apply: Manufacturer means Enduraplas LLC. Purchase Date means the date upon which the applicable goods were purchased by the original end user.
Page 20: Parts Breakdowns
OVERVIEW 35 37 DETAIL C DETAIL A DETAIL D DETAIL B 34 38 33 38 Brine Master ®...
Page 21 DETAIL VIEW A DETAIL A Version 1.2...
Page 22 DETAIL VIEW B DETAIL B Brine Master ®...
Page 23 DETAIL VIEW C AND D DETAIL C DETAIL D Version 1.2...
Page 24 Bracket for 3000 Gal Brine Master IMS00870OR-NF 870 Gal Flat Bottom Storage Tank AMBM3000 Brine Master 3000 Hopper AMBMSG3000 Brine Master 3000 Hopper Spill Guard CB234PPE51 2" Poly Pump 5Hp Elec Motor Single Phase CBMLS2216 MLS222 Y-Strainer 16 Mesh CPFTGE6...
Page 25 1-in MPT x 1-in FPT 304SS 90 Deg Elbow CV3RB10034 Reducer Bushing 1" MPT X 3/4" FPT CV3RB3414 3/4 x 1/4 Reducer Bushing CEC018 Brine Master 3000 Electrical Assembly CB300CAP 3-in Cap CLUESB020005 1-in EPDM Hose (Discharge to Hopper) CLUESB020005...
Page 26 PARTS LIST ITEM NO. PART # Description QTY. CBM300BRB45 3 Flange x 3 Hose Barb x 45 CVPBV516 5/16 inch Diverting Valve 5/16" PVC On/Off Valve Poly Valve Push to CVST516PTC516 Connect CFBE00M0000M 1/4 NPT 5/16 Brass Push-to-Connect Male Elbow CLUVGC04503 3/16ID, 5/16 OD Polyethylene Tubing-1 CLUVGC04503...
Page 27 ACTIVATE YOUR 10-YEAR TANK WARRANTY How to Activate To double your 5-year tank warranty, visit www.camionsystems.com/warranty/ and register this product. Watch Instruction Videos: www.youtube.com Discover More Helpful Tips: www.IceControlTraining.com Version 1.2...
Page 28 ® CAMION by Enduraplas 1 (877) 265-9929 cs@camionsystems.com www.camionsystems.com 113 1st Street, Neche ND 58265, USA A Brand By Enduraplas Discover More Helpful Tips: www.IceControlTraining.com Copyright © Enduraplas. All Rights Reserved.
