- Page 1 BRINE MASTER 1600 ® OWNER’S MANUAL BRINE MASTER 1600 Product Code: IMSBM1600 Version 1.0 Copyright © Enduraplas. All Rights Reserved.
-
Page 2: Table Of Contents
English CONTENTS INTRODUCTION WARNINGS 4 - 5 GETTING STARTED 6 - 7 OPERATION 8 - 11 MAINTAINING TROUBLESHOOTING WARRANTY 14 - 17 PARTS BREAKDOWNS 18 - 22 Brine Master ®... -
Page 3: Introduction
English INTRODUCTION Congratulations! You now own an Camion™ Brine Master®. Durable design and construction assure you a lifetime of extreme performance. Take a look through this owner’s manual to learn how the pros use their Camion™ Brine Master®. Watch Instruction Videos: www.youtube.com... -
Page 4: Warnings
English WARNINGS 1. To ensure your own safety and that of others, you must comply with all relevant environmental, work place health, safety legislation and codes of practice. 2. Select and wear appropriate Personal Protection Equipment in accordance with the label of the product you intend to use. - Page 5 English Discover More Helpful Tips: www.IceControlTraining.com Version 1.0...
-
Page 6: Getting Started
English GETTING STARTED Electrical Requirements The Brine unit requires a 115 volt, 20 amp circuit to operate. It comes supplied with waterproof wiring and plug ready to hook up. You will need a 115 volt outlet with a 20 amp breaker in your box. - Page 7 English GETTING STARTED Setting-up your Brine Master® 4) To achieve best results with your brine maker, use a good quality salt. The quality of your salt aides in speeding up the brining process and will eliminate having to clean out screens as often. 5) It is recommended to first fill the unit with fresh water to ensure there are no leaks and your power supply is correct.
-
Page 8: Operation
English OPERATION First Batch of Brine 1) To start your first batch turn on your pump and open valves #1 and #3 to fill your hopper. 2) Fill your hopper to the bottom of the screen with fresh water. 3) You can begin filling your hopper with salt. - Page 9 English OPERATION First Batch of Brine 6) Reference the site gauge tube on your holding tank - Once it reaches 400 gallons stop adding fresh water - We recommend marking or putting a piece of tape to note this level. 7) Now you will start the brining process.
- Page 10 English OPERATION First Batch of Brine 12) As you are discharging your finished batch to your storage tank, fill your hopper with salt for your next batch. This will force some of the brine into your holding tank increasing your batch size. 13) Once all brine is discharged rotate valves to load fresh water and repeat steps.
- Page 11 English Version 1.0...
-
Page 12: Maintaining
English MAINTAINING The unit requires proper care for longevity and proper operation. Follow all requirements for pump and motor by reviewing their manuals that are included. At the beginning of each brining session ensure there are no hose or fitting leaks. The filter screen should be cleaned of any debris that would cause a flow issue. -
Page 13: Troubleshooting
English TROUBLESHOOTING CONDITION REMEDY Flow rate is dropping 1) Check for a blockage on the screen. Hopper is backing up 1) Ensure there is no blockage on or overflowing internal hopper screen. 2) Clean debris or salt away from the screen. -
Page 14: Warranty
English WARRANTY LIMITED WARRANTY 1. Poly Tank Limited Warranty - Subject to other terms in this Limited Warranty, Manufacturer warrants to the original end user that this Tank will be free from material defects caused during the manufacturing process for a period of 5 years from the Purchase Date provided such warranty to the original end user shall be extended to 10 years from the Purchase Date if the original end user registers the Tank with Manufacturer within 30 days of the... - Page 15 English 3. Limitation of Liability under the Limited Warranty - In addition to those warranties disclaimed and excluded in clause 2 above, Manufacturer expressly further limits its warranty and liability under the Limited Warranty as set forth below in this clause 3. 3.1.
- Page 16 English 3.2. Without limiting the generality of clause 3.1: Manufacturer will not be liable for any personal injury, indirect or incidental damages, consequential losses, loss of liquids, loss of profit or any like claims whatsoever arising from any use of, or incidental to, or repairs to any of the Goods by a party other than Manufacturer;...
- Page 17 English 5. Claims and Questions - If you have questions about this Limited Warranty or to make a warranty claim, contact Manufacturer at: customercare@enduraplas.com 6. Definitions - For this Limited Warranty the following definitions apply: Manufacturer means Enduraplas LLC. Purchase Date means the date upon which the applicable goods were purchased by the original end user.
-
Page 18: Parts Breakdowns
OVERVIEW DETAIL D DETAIL A DETAIL C DETAIL B Brine Master ®... - Page 19 DETAIL VIEW A AND B DETAIL A 35 24 DETAIL B Version 1.0...
- Page 20 DETAIL VIEW C AND D DETAIL C DETAIL D Brine Master ®...
- Page 21 Screen for 1600 Gal. Brine Master CSLC635 Bracket for 1600 Gal Brine Master IMS00550OR-NF 550 Gal Flat Bottom Storage Tank AMBM1600 Brine Master 1600 Hopper APAMT002 2-in Poly Pump CBTF200 2 Poly Tank Flange Assembly CBM220MPT 2 FP Manifold x 2 Male Thread...
- Page 22 PARTS LIST ITEM NO. PART # Description QTY. CHNSN0323 3/8" SS Nylock Nut CHUS031234001 1-in U-Bolt CBM200BRB 2 inch Manifold Barb CLUPEB10009 2-in hose pump discharge to tank CV3RB10034 Reducer Bushing 1" MPT X 3/4" FPT CBGHFT075MPT .75-in male NPT x .75-in female garden hose AXFM01 1-in Jobe Megaflow Valve CBHB20090...
- Page 23 ACTIVATE YOUR 10-YEAR TANK WARRANTY How to Activate To double your 5-year tank warranty, visit www.camionsystems.com/warranty/ and register this product. Watch Instruction Videos: www.youtube.com Discover More Helpful Tips: www.IceControlTraining.com Version 1.0...
- Page 24 ® CAMION by Enduraplas 1 (877) 265-9929 cs@camionsystems.com www.camionsystems.com 113 1st Street, Neche ND 58265, USA A Brand By Enduraplas Discover More Helpful Tips: www.IceControlTraining.com Copyright © Enduraplas. All Rights Reserved.
