BRINE MASTER 3000

OWNER'S MANUAL

BRINE MASTER 3000

Product Code:

IMSBM3000

Version 1.1

Table of Contents

Need help?

Do you have a question about the BRINE MASTER 3000 and is the answer not in the manual?

Questions and answers

Summary of Contents for CAMION BRINE MASTER 3000

Page 2: Table Of Contents
English CONTENTS INTRODUCTION WARNINGS 4 - 5 GETTING STARTED 6 - 9 OPERATION 10 - 11 MAINTAINING 12 - 13 TROUBLESHOOTING WARRANTY 14 - 17 PARTS BREAKDOWNS 18 - 24 Brine Master ®...
Page 3: Introduction
English INTRODUCTION Congratulations! You now own an Camion™ Brine Master®. Durable design and construction assure you a lifetime of extreme performance. Take a look through this owner’s manual to learn how the pros use their Camion™ Brine Master®. Watch Instruction Videos: www.youtube.com...
Page 4: Warnings
English WARNINGS 1. To ensure your own safety and that of others, you must comply with all relevant environmental, work place health, safety legislation and codes of practice. 2. Select and wear appropriate Personal Protection Equipment in accordance with the label of the product you intend to use.
Page 5 English Discover More Helpful Tips: www.IceControlTraining.com Version 1.1...
Page 6: Getting Started
English GETTING STARTED Electrical Requirements The Brine unit requires a 220 volt, 30 amp circuit to operate. It comes supplied with wiring and plug ready to hook up. You will need a 220 volt outlet with a 30 amp breaker in your box.
Page 7 English GETTING STARTED Setting-up your Brine Master® 4) To achieve best results with your brine maker, use a good quality salt. The quality of your salt aides in speeding up the brining process and will eliminate having to clean out screens as often. 5) Fill your unit with fresh water and cycle to ensure there is no leaks or issues with power supply.
Page 8 English GETTING STARTED Calibrating your Brine Master® Your unit comes preprogrammed from the factory. You will only have to reset your cell constant. 1) After all setup is complete and you begin mixing brine, you will adjust your cell constant up or down. Up if your dig- ital readout is reading lower than your floating hydrometer and down if your digital readout is reading higher than...
Page 9 English GETTING STARTED Calibrating your Brine Master® 5) To adjust your cell constant, hold the Cal and Mode button simultaneously. 6) The menu will come up. Now press enter to continue. Click the first menu option and press enter. 7) You will adjust this constant up or down.
Page 10: Operation
English OPERATION First Batch of Brine 1) On your first batch allow water to gravity feed until jet nozzles are submerged this helps with water splashing. 2) Continue by turning on pump to fill your hopper to the bottom of the screen with fresh water.
Page 11 English OPERATION First Batch of Brine 6) Once salt is added, continue filling the system with fresh water until the holding tank is at 600 gallons. Reference the site gauge tube. - We recommend marking or putting a piece of tape to note this level.
Page 12: Maintaining
English MAINTAINING The unit requires proper care for longevity and proper operation. Follow all requirements for pump and motor by reviewing their manuals that are included. At the beginning of each brining session ensure there are no hose or fitting leaks. There is a 3”...
Page 13: Troubleshooting
English MAINTAINING If you notice your flow rate has decreased to under 100 gpm on flowmeter it is required to disassemble filter by shutting off unit and opening drain valve. Then unscrew housing and clean screen inside. Reassemble and continue use. Always Clean unit with fresh water at the end of every season to clean out all brine left in brine maker to insure proper operations for the following years.
Page 14: Warranty
English WARRANTY LIMITED WARRANTY 1. Poly Tank Limited Warranty - Subject to other terms in this Limited Warranty, Manufacturer warrants to the original end user that this Tank will be free from material defects caused during the manufacturing process for a period of 5 years from the Purchase Date provided such warranty to the original end user shall be extended to 10 years from the Purchase Date if the original end user registers the Tank with Manufacturer within 30 days of the...
Page 15 English 3. Limitation of Liability under the Limited Warranty - In addition to those warranties disclaimed and excluded in clause 2 above, Manufacturer expressly further limits its warranty and liability under the Limited Warranty as set forth below in this clause 3. 3.1.
Page 16 English 3.2. Without limiting the generality of clause 3.1: Manufacturer will not be liable for any personal injury, indirect or incidental damages, consequential losses, loss of liquids, loss of profit or any like claims whatsoever arising from any use of, or incidental to, or repairs to any of the Goods by a party other than Manufacturer;...
Page 17 English 5. Claims and Questions - If you have questions about this Limited Warranty or to make a warranty claim, contact Manufacturer at: customercare@enduraplas.com 6. Definitions - For this Limited Warranty the following definitions apply: Manufacturer means Enduraplas LLC. Purchase Date means the date upon which the applicable goods were purchased by the original end user.
Page 18: Parts Breakdowns
OVERVIEW 36 38 DETAIL C DETAIL A DETAIL D DETAIL B 35 39 34 39 37 39 39 34 39 Brine Master ®...
Page 19 DETAIL VIEW A DETAIL A 30 31 31 30 Version 1.1...
Page 20 DETAIL VIEW B DETAIL B 18 10 Brine Master ®...
Page 21 DETAIL VIEW C AND D DETAIL C DETAIL D Version 1.1...
Page 22 Bracket for 3000 Gal Brine Master IMS00870OR-NF 870 Gal Flat Bottom Storage Tank AMBM3000 Brine Master 3000 Hopper AMBMSG3000 Brine Master 3000 Hopper Spill Guard 2-in Poly Pump 5Hp Electric Motor Single CB234PPE51 Phase CBMLS2216 MLS222 Y-Strainer 16 Mesh CPFTGE5...
Page 23 PARTS LIST ITEM NO. PART # Description QTY. CHNS0423 7/16 Nylock Nut CHNSH0323 3/8" SS Hex Nut CHWZF045 7/16 flat washer CHWSF033 3/8 SS Flat washer EX200RS (Toroidal /Inductive Conductivity CEC016 Sorsor) CBV25270 Straight Mounting Bracket CBBF220BD 2 Thread Full Port Flange CBSL07590 3/4 Poly Street Elbow 90 CFPN04M04M...
Page 24 1-in MPT x 1-in FPT 304SS 90 Deg Elbow CV3RB10034 Reducer Bushing 1" MPT X 3/4" FPT CV3RB3414 3/4 x 1/4 Reducer Bushing CEC018 Brine Master 3000 Electrical Assembly CB300CAP 3-in Cap CLUESB020005 1-in EPDM Hose (Discharge to Hopper) CLUESB020005...
Page 25 ACTIVATE YOUR 10-YEAR TANK WARRANTY How to Activate To double your 5-year tank warranty, visit www.camionsystems.com/warranty/ and register this product. Watch Instruction Videos: www.youtube.com Discover More Helpful Tips: www.IceControlTraining.com Version 1.1...
Page 26 ® CAMION by Enduraplas 1 (877) 265-9929 cs@camionsystems.com www.camionsystems.com 113 1st Street, Neche ND 58265, USA A Brand By Enduraplas Discover More Helpful Tips: www.IceControlTraining.com Copyright © Enduraplas. All Rights Reserved.

This manual is also suitable for:

Imsbm3000
