- Page 1 HAMPTON CONVERTIBLE LOFT BOOKCASE ASSEMBLY INSTRUCTION Date: 2015-June-23 Rev: www.pbteen.com Page 1 of 7...
- Page 2 Important Safety Instructions: Please read all instructions carefully before assembling this bookcase. For your safety, assembly by two or more adults is strongly recommended. Keep these instructions for future use. Use only vendor-supplied hardware to assembly this item. Using unauthorized hardware could jeopardize the structural integrity of the item.
- Page 3 N – Half Moon O – Philips Head P – Shelf Support Q – Pan Head Washer Screw Screw 6 x 19(mm) 5x13x16x1.5(mm) 8 x 15(mm) 1/4”x 24 x8(mm) 4pcs 21pcs 8pcs 8pcs TOOLS REQUIRED (but not included): Phillips Head Screwdriver Assembly Instruction Steps: 1.
- Page 4 5. With the help of the locating dowel, place the Bottom Panel (E) and insert the locating dowel of Left, Right and Center Panel (B,C&D) to the Bottom Panel (E). 6. Secure the Bottom Panel (E) by inserting the Half Moon Washer (N), follow by Flat Washer (M), Spring Washer (M) and Long Allen Bolt (J) –...
- Page 5 7. Place the Bookcase Base (F) on the Bottom Panel (A) with the help of the locating dowel as shown below. Secure the Bookcase Base (F) to the Bottom Panel (A) by inserting the Flat Washer (M), follow by Spring Washer (L) and Short Allen Bolt (K) –...
- Page 6 9. Place the Back Panel (G) to the back of the Bookcase as shown below. Secure the Back Panel (G) by inserting the Philip Head Screw x 21pcs into the pre-drilled of the Back Panel (G). Tighten it with using the Philip Head Screwdriver (Not Included) as shown below.
- Page 7 12. To keep the Bookcase balance, adjust the levelers at the underneath of the Bookcase legs as shown below. 13. Assembly is completed. Care Instructions: Dust often using a clean, soft, dry and lint-free cloth. Blot spills immediately and wipe with a clean, damp, cloth. ...
