PB TEEN Hearts Wall Pinboard Assembly Instructions

Hearts Wall Pinboard Black/White
(Set of Two)

Parts Included:

Two hearts are provided and both include two D-rings on the back for hanging on a wall.

Mounting Instructions:

1. Hold one of the hearts against the wall at a desired mounting location so that the back of the heart faces
toward you, so that you can see the two D-rings. Hold the heart as level as possible and then mark
the wall immediately above the two D-rings. Set the item aside.
2. Now use a level to make sure that the two marks of Step (1) are level and adjust if necessary.
These two marks will be the location of the screws and anchors.
3. If either mark happens to align with a wall stud (use a stud finder to determine this), do not use the
provided anchors because they cannot penetrate wood. If a mark does align with a stud, only use one
provided screws at this mark. Use the screwdriver to secure a screw at the mark directly into the wall and stud.
Rotate the screw clockwise until the screw head is about 3/8" from the wall.
4. For each mark that does not align with a wall stud: Place a Phillips screwdriver into the recess of an anchor and
position its tip at one of the insertion point marks. Push the anchor into the wall as you rotate it clockwise. The
anchor will drive itself into the wall like a large screw. Continue rotating clockwise until the wide end of the anchor
is even with the wall.
5. Secure a provided screw into each installed anchor. Use the screwdriver to rotate the screw clockwise until the
screw head is about 3/8" from the wall.
6. Hold the heart against the wall and align and engage the D-rings with the projected screw heads.

Care Instructions:

Wipe with a soft, dry cloth.
Do not use strong chemicals or abrasive cleaners.
(4) Screws
(4) Anchors
Thank you for your purchase.
The provided hardware is meant to be used
with drywall or wall studs. If your walls are
made from a material (concrete, plaster, etc.),
please consult your local hardware store for
assistance in selecting the proper hardware.

Tools:

Phillips Screwdriver, Level, Pencil,
Stud Finder
www.pbteen.com
