Server CP-MEC3 Manual page 6

ASSEMBLY
INSTALL SMALL O-RING
1
into seal. Apply food equipment
lubricant on o-ring.
INSTALL SEAL
2
onto piston head. Apply food equipment
lubricant inside seal.
TIP: Flared end of seal should
face away from piston head.
SLIDE WASHER
3
onto piston.
SLIDE SPRING
4
onto piston
OPTIONAL: ADD GAGING COLLARS
onto head tube to reduce portion size.
Smaller collar: 3.7 mL reduction
Larger collar: 7.4 mL reduction
SLIDE LOCKING COLLAR
5
(thread side down) towards flared
end of head tube.
SLIDE HEAD INSERT
6
(beveled edge first) into head tube.
INSERT PISTON ASSEMBLY
7
into head tube assembly.
INSTALL KNOB
8
Press head tube down to compress
spring and expose piston threads.
Rotate knob clockwise to secure.
Page 6
WASH ALL PARTS PROPERLY
BEFORE EVERY USE.
See page 4.
