Lightspeed Mobile PA Quick Start Manual

Quick Start Guide
1
PLUG IN POWER SUPPLY TO THE MOBILE PA BEFORE FIRST USE
Mobile PA should be charged for at least 4-5 hours before first time use in order to achieve a full day use.
Connect the AC power cord into the DC power supply. Insert the connector into the Mobile PA and plug the power cord
into an electrical outlet. Mobile PA automatically powers on and the white Power light on the side panel will glow.
2
CHARGE THE MICROPHONES
Place the microphones into the integrated cradle charger. The microphone battery status light will glow red when it is
charging. When charging complete, the battery status light will glow green.
IR Receiver
Status Light
BLINKING BLUE/WHITE: PAIRING MODE
SOLID BLUE: PAIRING COMPLETE
Battery Light
BATTERY LOW
CHARGING IN PROGRESS
CHARGING COMPLETE
Power Light
POWER ON: SOLID WHITE
Power On and Levels Control
Set levels for audio input,
output and tone based on
selectors below.
Audio Output Volume Selector
Audio Input Volume Selector
Press and hold to pair
Bluetooth devices.
Tone Control Selector
Press and hold to pair
Lightspeed Media Connector
or companion speaker.
1
DC Power Jack
Connect AC cord
to electrical outlet.
1 If you wish to wirelessly connect two Mobile PA units together, please refer to the Mobile PA User Manual for connection and operating instructions.
Portable Audio System
DC POWER SUPPLY
Voice Priority
Switchable voice priority
function that mutes other
audio sources when the
microphone is in use to
ensure teacher's speech
is clearly heard.
Companion Speaker
1
(Optional)
2
Microphone
Charging Cradles
CHARGING IN PROGRESS
CHARGING COMPLETE
Removable Battery
Fast-charging battery
runs for a full school day
on a 4-5 hour charge.
AC POWER CORD
