Whalen BBAVT27-MBC Manual

27” audio tower
Hide thumbs Also See for BBAVT27-MBC:

Advertisement

Available languages

Available languages

Quick Links

Download this manual
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our customer service number and have your instructions and
parts list ready to provide the model name, part name or factory number:
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday - Friday
Or visit our web site 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
27" Audio Tower
Model # BBAVT27-MBC
ADULT ASSEMBLY REQUIRED
1-866-942-5362
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2021-10-14
LOT NUMBER:
DATE PURCHASED: /
Rev. 0001-D
/

Advertisement

loading

Related Manuals for Whalen BBAVT27-MBC

Summary of Contents for Whalen BBAVT27-MBC

  • Page 1 LOT NUMBER: DATE PURCHASED: / 27” Audio Tower Model # BBAVT27-MBC ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our customer service number and have your instructions and...
  • Page 2 G E N E R A L I N F O R M A T I O N , T I P S A N D T R I C K S 1. Please read the Assembly Instructions prior to assembling this product. 2.
  • Page 3 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel (Qty. 1) B- Upper Middle Shelf (Qty. 1) C- Lower Middle Shelf (Qty. 1) D- Bottom Shelf (Qty.
  • Page 4 Assembly Instructions ③ ④ ⑤ × × × NOTE: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make the assembly easier. 1. Unpack the unit and confirm that you have all the hardware and required parts. 2.
  • Page 5 Assembly Instructions ③ ④ ⑤ × × × 5. Attach the Lower Middle Shelf (C) and Bottom Shelf (D) to the Back Frame (E) with four 1-1/4” Bolts (3) and four Washers (4 and 5).
  • Page 6 Assembly Instructions B/C/D ③ ④ ⑤ × × × 6. Align and attach Left Leg (F) to the Lower Shelf Frames (B, C and D) with four 1-1/4” Bolts (3) and four Washers (4 and 5). 7. Repeat the same procedure to attach the Right Leg (G) on the other side.
  • Page 7 Assembly Instructions ④ ② ⑤ × × × 8. Fasten the Top Panel (A) into place with four 1” Bolts (2) and four Washers (4 and 5).
  • Page 8 Assembly Instructions ① × 9. Stand the unit upright. 10. Attach 2 Cable Wheels (H) onto the backside of the Back Frame (E) and tighten with the enclosed hex wrench. 11. The cable wheels allow you to organize, route and separate your component cords and cables to minimize tangling and signal interference.
  • Page 9 Assembly Instructions ⑥ × NOTE: You must install the Acrylic TV Stopper to prevent the TV from tipping when placing your flat panel television directly on the tower. Otherwise, skip to step 13 to remove the stopper template directly. 12. Remove the paper backing from the acrylic stopper (6), then properly align the acrylic stopper into the cut-out on the acrylic stopper template on the top panel (A).
  • Page 10 Assembly Instructions Tools required (not provided): Phillips screwdriver, stud finder, power drill and 1/8" drill bit. 14. Position the assembled unit at the desired location against a wall. If necessary, adjust the pre-attached Floor Levelers at the bottom of the Legs (F and G) to level the unit. Now, follow the instructions printed on the plastic bag containing the Tipping Restraint Hardware to attach the tip-over restraint to the Back Frame and the wall.

  • Page 11: Care And Maintenance

    Care and Maintenance ⚫ Use a soft, clean cloth that will not scratch the surface when dusting. ⚫ Use of furniture polishes is not necessary. Should you choose to use polishes, test first in an inconspicuous area. ⚫ Using solvents of any kind on your furniture may damage the finish. ⚫...

  • Page 12: Quality Guarantee

    Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
  • Page 13 NÚMERO de LOTE: FECHA de COMPRA: Torre de audio de 27” Modelo # BBAVT27-MBC ENSAMBLE POR ADULTO REQUERIDO Si tiene alguna pregunta acerca del ensamble o si le hace falta alguna parte, no devuelva este producto a la tienda donde lo compró . Por favor llame a nuestro departamento de ayuda al cliente teniendo su instructivo y lista de partes para proveer el modelo, nombre de parte o el nú...
  • Page 14 I N F O R M A C I Ó N G E N E R A L , R E C O M E N D A C I O N E S Y T R U C O S 1.
  • Page 15 Lista de partes y material de ferreterí a Por favor lea completamente las instrucciones y verifique que esté n todas las partes y partes de ferreterí a antes de iniciar el ensamblado. A- Panel superior l (Cant. 1) B- Repisa superior media (Cant. 1) C- Repisa inferior media (Cant.

  • Page 16: Instrucciones De Ensamble

    Instrucciones de ensamble ARRIBA ARRIBA ③ ④ ⑤ × × × NOTA: Por favor no apriete completamente todos los pernos, hasta que termine con el ensamble de las partes, despué s asegú rese de apretar todos los pernos, esto hará el ensamble má s fá cil. 1.
  • Page 17 Instrucciones de ensamble ARRIBA ARRIBA ③ ④ ⑤ × × × 5. Adjuntar la repisa inferior media (C) y la repisa inferior (D) al marco posterior (E) con 4 pernos de 1- 1/4” (3) y 4 arandelas (4 y 5).
  • Page 18 Instrucciones de ensamble B/C/D ③ ④ ⑤ × × × 6. Alinear y adjuntar la pata izquierda (F) a los marcos inferiores de repisa (B, C y D) con 4 pernos de 1- 1/4” (3) y 4 arandelas (4 y 5). 7.
  • Page 19 Instrucciones de ensamble ④ ② ⑤ × × × 8. Sujetar el panel superior (A) en su lugar con 4 pernos de 1” (2) y 4 arandelas (4 y 5).
  • Page 20 Instrucciones de ensamble ① × 9. Poner la unidad en posició n vertical. 10. Adjuntar 2 guí as de cable (H) en la parte posterior del marco posterior (E) y sujetar con la llave hexagonal. 11. Las guí as de cable le permiten organizar, encaminar, y separar sus cables para minimizar enredamientos e interferencia de señ...
  • Page 21 Instrucciones de ensamble ⑥ × NOTA: Debe instalar el tope acrí lico de TV para prevenir la TV de inclinarse cuando ponga su televisió n de pantalla plana directamente sobre la torre. De lo contrario, salte al paso 13 para retirar el templado del tope de acrí...
  • Page 22 Instrucciones de ensamble Herramientas requeridas (no incluidas): Desarmador estrella, localizador de barrotes, taladro elé ctrico y broca de 1/8”. 14. Posicionar la consola ensamblada en el lugar deseado en contra de la pared. Si fuera necesario, ajustar los niveladores de piso pre-adjuntados en la parte inferior de las patas (F y G) para nivelar la unidad. Seguir las instrucciones impresas en la bolsa de plá...

  • Page 23: Mantenimiento Y Cuidados

    Mantenimiento y Cuidados ⚫ Use una toalla suave y limpia para evitar dañ os y rayaduras. ⚫ Uso de cera para pulir muebles no es necesario. Si desea usar cera cheque en un á rea que no sea visible para verificar su funcionamiento. ⚫...
  • Page 24 Si este producto tiene algun defecto de ensamblado o material o si tiene alguna falla en uso normal, Nosotros lo repararemos o lo re-emplazaremos hasta por un añ o à partir de la fecha de compra. Todo producto de Whalen Furniture es diseñ...
