If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
1-866-942-5362 8:30 a.m. - 4:30 p.m. PST, Monday - Friday
ONLINE: www.whalenfurniture.com
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
54" TV Console
Model # BBAVCL54-SMB
ADULT ASSEMBLY REQUIRED
On-line Video Instruction Guides
Go to
www.guides.sellpoints.com
videos for assembling and installing your product. Enter the following
product number on the website.
BBAVCL54-SMB
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2016-03-18 Rev. 1 Factory: DONPEA
LOT NUMBER:
DATE PURCHASED: /
EMAIL: parts@whalenfurniture.com
to view step-by-step instructional
/
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Whalen TV Console BBAVCL54-SMB
Summary of Contents for Whalen TV Console BBAVCL54-SMB
- Page 1 LOT NUMBER: DATE PURCHASED: / 54" TV Console Model # BBAVCL54-SMB ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll free customer service number and have your instructions and parts list ready to provide the model name, part name or factory number: 1-866-942-5362 8:30 a.m.
- Page 2 M A X I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: 54" TV Console (BBAVCL54-SMB) DATE OF MANUFACTURE: April 2016 MADE IN CHINA FITS UP TO MOST 65”...
- Page 3 Important Before you begin: Open, identify and count all parts prior to assembly. Lay out parts on a flat and non- abrasive surface. You will need the parts identified on page 4 and 5 of this instruction manual. NOTE: IT IS VERY IMPORTANT TO USE GLUE WITH THE DOWELS. EXCESS GLUE CAN BE WIPED OFF WITH A DAMP CLOTH.
- Page 4 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel (Qty. 1) B- Fixed Shelf (Qty. 1) C- Bottom Panel (Qty. 1) D- Left Side Panel (Qty. 1) E- Right Side Panel (Qty.
- Page 5 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. (1) Cam Lock (2) Cam Bolt (3) M8 x 30 mm Wood Dowel (Qty. 18+1 extra) (Qty. 18+1 extra) (Qty.
- Page 6 Assembly Instructions 1. Unpack the unit and confirm that you have all the hardware and required parts. Assembly the unit on a carpeted floor or empty carton to avoid any scratch. 2. Lay out the Top Panel (A), Fixed Shelf (B), Bottom Panel (C), Left and Right Side Panels (D and E) with the holes facing up.
- Page 7 Assembly Instructions 5. Glue four Wood Dowels (3) into the inner holes of the Fixed Shelf (B) at both ends. 6. Align the large holes on the Left Side Panel (D) with the inserted Wood Dowels (3) on the Fixed Shelf (B), then press them together.
- Page 8 Assembly Instructions 12. Align and attach Left and Right Lower Partition Panels (F and G) to the support rails of the Fixed Shelf (B) by using four Wood Dowels (3) and four Cam Locks (1), as shown. 13. Glue eight Wood Dowels (3) into the inner holes of both Side Panels (D and E) and Partition Panels (F and G).
- Page 9 Assembly Instructions 16. Align and attach the Left Side Frame (N) to the Left Side Panel (D) using four 25 mm Bolts (7) from inside through the mounting holes and loosely screw into the Side Frame. 17. Repeat the previous step to attach the Right Side Frame (O) at the opposite end. NOTE: DO NOT fully tighten the bolts.
- Page 10 Assembly Instructions 19. Align and attach the assembled Cross Stretcher (P and Q) between the Side Frames (N and O) by using four 15 mm Bolts (8) with the Washers (9 and 10) through the end brackets and screw into place. 20.
- Page 11 Assembly Instructions 21. Now, go back and tighten all cam locks and screws, make sure that all the parts are tight and there are no gaps between the parts, this will help keep the unit square. 22. Ask for assistance to stand the unit upright. Unfold the Back Panel (M) and position it to the back edges of the assembled unit.
- Page 12 Assembly Instructions 24. Extend the two Hinge Arms that are pre-attached on one Door Panel (I) and attach them to the Hinge Bases on the Right Side Panel (E). Loosen the bolt on the back of Hinge Base for an easy fit. Align and insert the “U”...
- Page 13 Assembly Instructions Tools required: Phillips screwdriver, Power Drill, 3/8” Drill Bit and Rubber Mallet. 29. Position the assembled TV console at the desired location against a wall. If necessary, adjust the pre-attached Floor Levelers on the bottom of the Side Frames (N and O) to level the unit. Now, follow the instructions printed on the plastic bag containing the Tipping Restraint Hardware to attach the tip-over restraint between the console and the wall.
-
Page 14: Care And Maintenance
Should this product be defective in workmanship or materials, or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
