If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
Or visit our website 24 hours a day, 7 days a week for product assistance at
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
60" TV Console
Model # BBAVC60-MBC
ADULT ASSEMBLY REQUIRED
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday to Friday
www.whalenfurniture.com
Or e-mail your request to parts@whalenfurniture.com
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Date 2017-04-09 Rev. 0001-A Factory: FOCIDI
1-866-942-5362
LOT NUMBER:
DATE PURCHASED:
/
/
Advertisement
Related Manuals for Whalen BBAVC60-MBC
Summary of Contents for Whalen BBAVC60-MBC
- Page 1 LOT NUMBER: DATE PURCHASED: 60" TV Console Model # BBAVC60-MBC ADULT ASSEMBLY REQUIRED If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store where it was purchased. Please call our toll-free customer service number and have your...
- Page 2 M AX I M U M R E C O M M E N D E D W E I G H T L O A D S MANUFACTURER: Whalen Furniture Manufacturing CATALOG: 60" TV Console (BBAVC60-MBC) MADE IN CHINA FITS UP TO MOST 70”...
- Page 3 Parts and Hardware List Please read completely through the instructions and verify that all listed parts and hardware are present before beginning assembly. A- Top Panel (Qty. 1) B- Middle Shelf (Qty. 1) C- Bottom Shelf (Qty. 1) D- Back Frame (Qty. 1) E- Left Leg (Qty.
- Page 4 Assembly Instructions Flat Washer 1-1/4” Bolt Lock Washer (2 used in this step) (2 used in this step) (2 used in this step) ③ ④ ⑤ NOTE: Please do not fully tighten all bolts until you finish assembling all parts. Once assembled, go back and fully tighten all bolts.
- Page 5 Assembly Instructions Flat Washer Lock Washer 1-1/4” Bolt (2 used in this step) (2 used in this step) (2 used in this step) ④ ⑤ ③ 4. Fasten the Middle Shelf (B) to the Back Frame (D) with two 1-1/4” Bolts (3) and two Washers (4 and 5).
- Page 6 Assembly Instructions Flat Washer Lock Washer 1-1/4” Bolt (2 used in this step) (2 used in this step) (2 used in this step) ④ ⑤ ③ 5. Attach the Bottom Shelf (C) to the Back Frame (D) with two 1-1/4” Bolts (3) and two Washers (4 and 5).
- Page 7 Assembly Instructions 1-1/4” Bolt Lock Washer Flat Washer (6 used in this step) (6 used in this step) (6 used in this step) ③ ④ ⑤ 6. Align and attach Left Leg (E) to the Lower Shelf Frames (B and C) with three 1-1/4” Bolts (3) and three Washers (4 and 5).
- Page 8 Assembly Instructions 1” Bolt Flat Washer Lock Washer (4 used in this step) (4 used in this step) (4 used in this step) ② ⑤ ④ 8. Fasten the Top Panel (A) into place with four 1” Bolts (2) and four Washers (4 and 5).
- Page 9 Assembly Instructions 5/8” Bolt (4 used in this step) ① 9. Stand the unit upright. 10. Attach 2 Cable Wheels (G) onto the backside of the Back Frame (D) and tighten with the enclosed hex wrench. 11. The cable wheels allow you to organize, route and separate your component cords and cables to minimize tangling and signal interference.
- Page 10 Assembly Instructions Acrylic Stopper (1 used in this step) ⑥ NOTE: You must install the Acrylic TV Stopper to prevent the TV from tipping when placing your flat panel television directly on the console. 12. Remove the paper backing from the acrylic stopper (6), then properly align the acrylic stopper into the cut-out on the acrylic stopper template on the top panel (A).
- Page 11 Assembly Instructions Tools required: hex wrench (provided), Phillips screwdriver, mallet, power drill, and 3/8” drill bit. 14. Position the assembled unit at the desired location against a wall. If necessary, adjust the pre- attached Floor Levelers at the bottom of the Legs (E and F) to level the unit. Now, follow the instructions printed on the plastic bag containing the Tipping Restraint Hardware to attach the tip-over restraint to the Back Frame and the wall.
-
Page 12: Care And Maintenance
Should this product be defective in workmanship or materials or fail under normal use, we will repair or replace it for up to one (1) year from date of purchase. Every Whalen Furniture product is designed to meet your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
