Installation Of The Oven Door

Figure 21 Figure 22
Figure 21.1 Figure 21.2 Figure 22.1 Figure 22.2
Completely open Bring the hinge Afterwards, close To remove the
the oven door lock to the widest the oven door as to oven door, pull it
by pulling it to angle as shown in lean on the hinge upwards by holding
yourself. After figure 21.2. Bring lock as shown in it with both hands
wards, perform both hinges figure 22.1. when close to the
the unlocking connecting the closed position
process by pulling oven door to as shown in
the hinge lock the oven to the figure 22.2.
upwards with the same position.
help of a screw
driver as shown
in figure 21.1.
In order to re-place the oven door, perform the abovementioned steps in reverse.
