TAKARA BELMONT SHAMPOO EQUIPMENT
YUME ESPOIR
YUME SUITE
YUME NOBLE
Model No
Operating Instructions
Thank you for purchasing this Takara Belmont product.
The instructions contained in this booklet should be thoroughly read and understood before use.
Using this product before reading this operating instructions may result in an accident.
This product is professional shampoo equipment for use in a beauty salon.
Only use this product for its intended purpose and do not use it for non-hairdressing work.
Keep this instruction and refer back to them when required.
For installation and assembly of this product, ask our company or a contractor designated by us.
Basin body : EX-ESYM* / EX-ESSS*
Seat body
: SC-ESF* / SC-ESL* / SC-YMSI*
Seat
: SU-ESB* / SU-ESP* / SU-YMSI* / SU-YMNB*
Base plate : EA-ESBP
Image is of  EX-ESSS*/SC-ESF*/SU-ESBF*/EA-ESBP
1
EX-ESSS*/SC-YMSI*/SU-YMSI*/EA-ESBP
EX-ESYM*/SC-YMSI*/SU-YMNB*/EA-ESBP
2022.09 Version 9
No.1A04NJD0
