Black Electric Single Motor Desk Frame
Instruction Manual
SKU: STAND-E-102B
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-e-102b
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
1
309-278-5303
Advertisement
Table of Contents
Related Manuals for Vivo STAND-E-102B
Summary of Contents for Vivo STAND-E-102B
- Page 1 Black Electric Single Motor Desk Frame Instruction Manual SKU: STAND-E-102B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-e-102b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual and do not exceed weight capacity.
- Page 3 TOOLS NEEDED Phillips Screwdriver DO NOT EXCEED WEIGHT CAPACITY. 110 lbs Failure to do so may result in serious injury. (50kg) Drill Including monitors, the weight capacity is 154 lbs (70kg). ASSEMBLY STEPS STEP 1 Loosen the two set screws on the Telescopic Crossbar (A) using the 4mm Allen Wrench (T-A). Adjust the crossbar length to suit the desktop.
- Page 4 Attach the Side Brackets (E) to both ends of the frame using four M6x12mm Screws (S-A). Tighten with the 4mm Allen Wrench (T-A). STEP 4 If you are using a VIVO desktop please follow the manual that came with it. Otherwise, place frame upside down on desktop and drill pilot holes for screws.
- Page 5 STEP 6 Position the frame upright. Loosen the knobs on the Sync Rod (B) and extend the hex shaft. Insert hex shaft into the Leg (I), making sure the metal retaining ring makes contact with the leg. While holding the hex shaft with one hand, extend sync rod onto the spline shaft of the motorized leg.
- Page 6 STEP 8 Connect Motorized Leg (H) to the Control Panel (K1). Connect Splitter Cable (O2) to Control Panel (K2). Connect Splitter Cable (O1) to AC Adapter (F). Connect the Power Cable (J) to the AC Adapter (F). - Used in manual #2 DC plug Used in manual #2 STEP 9...
- Page 7 If you are using a VIVO desktop, Refer to the manual that came with your desktop. If you are not using a VIVO desktop, place the desktop on the frame, and secure the desktop using the ST4.2X20mm Screws (S-B). Make sure your desktop is greater than 1" (25mm) thick using screws (S-B).
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
