Electric Height Adjustable Dual Monitor Stand Instruction Manual SKU: STAND-E-102B Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-e-102b GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
ASSEMBLY STEPS STEP 1 Attach Upper Clamp Bracket (C) to the bottom of the Electric Stand (A) using M6x12mm Screws (S-A) and a 4mm Allen Wrench (T-A). STEP 2 For desktops between 10-55mm (0.40”-2.15”), align the key slots on Lower Clamp Bracket (B) with the screws on Upper Clamp Bracket (C).
Page 4
STEP 3 First, clamp the stand assembly onto desk. Press the Clamp Cable Clip (D) onto Upper Clamp Bracket (C). Option A: Dual Monitor Setup STEP 4 Partially loosen screw on Dual Arm (E) with 6mm Allen Wrench (T-B) and slide Dual Arm (E) onto the post of Electric Stand (A).
Page 5
STEP 5 Re-tighten screw on Dual Arm (E) with arm assembly at the top of the post using the 6mm Allen Wrench (T-B). Attach an Arm Cable Clip (G) onto each arm segment. Note: The final arm position will be determined in step 13. Option B: Single Monitor Setup STEP 6 Remove a single arm segment and the cable clip from Dual Arm (E) using the 6mm Allen...
Page 6
STEP 7 Loosely assemble the cable clip on Single Arm Bracket (F) using the 6mm Allen Wrench (T-B). Cable Clip Clip Screw STEP 8 Attach the single arm segment to Single Arm Bracket (F) using the 6mm Allen Wrench (T-B). Note: This screw adjusts the joint tension.
STEP 9 Re-tighten screw on Single Arm Bracket (F) with arm assembly at the top of the post using the 6mm Allen Wrench (T-B). Attach an Arm Cable Clip (G) onto each arm segment. Note: The final arm position will be determined in Step 13. Monitor Installation STEP 10 Attach VESA Bracket (H) to monitors using either M4x12mm or M5x12mm bolts (M-A,M-B)
Page 8
STEP 11 Slide monitors onto tilt joint located on the arm assembly. Lock VESA plate (H) in place with Screw Cap (S-B), M3x8mm Screw (S-C) and a Phillips Screwdriver. Adjust monitor height alignment by turning Screw Cap (S-B) by hand or using 6mm Allen Wrench (T-B). Note: If you are having an issue with a monitor tilting down once installed on the arm, refer to Step 17 to tighten down the tilt joint.
Page 9
STEP 13 Initial Setup Procedure: Referring to the control panel instruction manual, ensure the panel display is set to adjust frame height (see the “Shift Device Display” section) and move your desk frame to a comfortable level for your normal sitting position. It is recommended to follow general ergonomic guidelines for working posture while considering your desk frame height.
Page 10
STEP 14 Setting Memory Positions: Referring to the control panel instruction manual, ensure the panel display is set to adjust stand height. In your normal sitting position, move the stand until the monitors are at a comfortable level, switching between frame and stand adjustment on the panel display as necessary.
Page 11
STEP 15 Route cables through Arm Cable Clips (G) and Cable Sleeve (I). Make sure there is enough slack in the cables and sleeve when the electric stand is at its tallest height. Use scissors to cut away excess cable sleeve length. STEP 16 Adjust monitors as desired.
Page 12
AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
