Curt Manufacturing 16050 Installation Manual

INSTALLATION MANUAL

Level of Difficulty

Easy
Installation difficulty levels are based on time
and effort involved and may vary depending on
the installer level of expertise, condition of the
vehicle and proper tools and equipment.

Weight Carrying Capacity

Gross trailer weight (GTW)
Tongue weight (TW)

Parts List

Item Qty Description
1 1 Roller mount, rear assembly
2 1 Roller mount, front assembly
3 2 Base plate
4 8 Carriage bolt, M12
5 8 Serrated flange nut, M12

Tools Required

Ratchet Socket set
Torque wrench Hex drive, M10
CURTMFG.COM
• PRODUCT SUPPORT: 877.287.8634
WARNING
Never exceed the vehicle manufacturer's recommended towing capacity.
Product Photo
30,000 lbs.
7,500 lbs.
NOTICE
Visit www.curtmfg.com for a full-color copy of this
instruction manual, as well as helpful videos, guides and much more!
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
Periodic inspection of your product should be performed
to ensure all hardware and / or components remain secure.
To help prevent damage to the product or vehicle, refer to the specified
torque specifications when securing hardware during the installation process.

Product Registration and Warranty

CURT stands behind our products with industry-leading warranties. To get copies of the product
warranties, register your purchase or provide feedback, visit: warranty.curtgroup.com/surveys
• 16050-INS-RA • 10/29/2021 • ECN8901 • PAGE 1
16050
