Appliance parts and control elements

Appliance and accessories
(1) Display
(2) Control panel
(3) Button to open door
(4) Turntable drive
Control panel
Appliance parts and control elements
(5)
(8)
(9)
(10)
(11)
(12)
(4)
(7) (6)
(5) Door-locking mechanism
(6) Oven rack
(7) Roller ring
(8) Turntable
(9) Control dial for setting programmes
(10) Control dial for setting time and weight
(11) "Start" button
(12) "Pause/Stop" button
Page EN-11
