S
PECIFICATIONS
Power Supply
Input Voltage
HDSL Line
Output Voltage
Output Power
HDSL Line Code
HDSL Line Rate
HDSL Reach
Maximum Line Attenuation
Environment
Operating Temperature
Operating Humidity
Altitude
Compliance
NEBS
ESD
Power and Lightning
Human Safety
Emissions Radiation and Immunity
Dimensions
Height
Width
Depth
Weight
DS0s HDSL Line Rate
4 262 kb/s
6 392 kb/s
2
-42.5 Vdc to -56.0 Vdc
+ 140 Vdc (maximum)
27 W (maximum)
2B1Q
See Table 1, "HDSL Lines," on page 2
See Table 1, "HDSL Lines," on page 2
See Table 1, "HDSL Lines," on page 2
-40° F to +150° F (-40° C to +65° C)
5% to 95% noncondensing
-200 ft to 13,000 ft (-60 m to 4,000 m)
SR-3580 for Level 3
Per GR-1089-CORE
Per GR-1089-CORE
UL 1950 for Restricted Access
Per GR-1089-CORE for Class A equipment
5.50 in. (14.0 cm.)
1.10 in. (2.8 cm.)
10.25 in. (26.0 cm.)
1.00 lbs. (0.5 kg.)
Table 1.

HDSL Lines

Maximum Attenuation
45.9 dB
41.6 dB
January 6, 2003
HDSL Reach
26 AWG 24 AWG 22 AWG
15.0 kft 21.6 kft 31.2 kft
4.6 km 6.6 km 9.5 km
12.5 kft 18.0 kft 25.2 kft
3.8 km 5.5 km 7.7 km
SCP-PLL735-010-03H
19 AWG
49.7 kft
15.1 km
37.8 kft
11.5 km
PLL-735 Lists 1, 2 and 3
