# 20-10-13
1 / 9
MODEL #
CM7272 T- VN
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
3 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM7272-VN
Summary of Contents for Furniture of America CM7272-VN
- Page 1 MODEL # CM7272 T- VN Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Phillips Screwdriver (Not Included) 3 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X 9...
- Page 5 CM7272 - T- VN #1 1pc #2 1pc #3 2pcs #4 4pcs Ø5/16" Support Leg Side Rail Headboard Footboard 30x30x270mm #8 1pc #5 1set #6 2pcs #7 2pcs Slat (13pcs) Front Leg Centre Rail Rear Leg #A 8pcs #B 8pcs #C 8pcs #D 1pc Bolt...
- Page 6 CM7272 - T-VN is packed in 2 cases Carton Disignation Part Hardware Headboard #A x 8pcs Footboard #B x 8pcs Support Leg 30x30x270mm #C x 8pcs Slat (13pcs) CM7272 - T -HBFB-VN #D x 1pc Front Leg #E x 34pcs Rear Leg Side Rail CM7272 - T-R-VN...
-
Page 7: Exploded View
Exploded View 7 / 9... - Page 8 ASSEMBLY INSTRUCTIONS Part #1 x1pc Part #2 x1pc Part #6 x2pcs Part #7 x2pcs Hardware #E x8pcs Align FB legs (#7) to the footboard (#2), then secure Attach HB legs (#6) to by using screws (#E). the headboard (#1). Secure bolts (#A) with washers (#B,C) 75% into headboard (#1) Part #3 x2pcs and footboard (#2).
- Page 9 ASSEMBLY INSTRUCTIONS Align center rail (#8) to the slats (#5), then secure by attaching support legs (#4) to the center rail (#8) and slats (#5). Adjust the leveler on the support legs (#4) according to ground level. Part #4 x4pcs Part #5 x1set Part...
