Summary of Contents for Furniture of America Euclid CM7206Q
- Page 1 For more information contact our team: service.ec@foagroup.com...
- Page 4 Prepare 6 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align legs (#2R/L) to the holes in the back of the headboard (#1), then secure with bolts (#A) as shown in the picture. Prepare 2 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A).
- Page 5 Hook the side rails (#5) through the gaps of the headboard (#1) and footboard (#4). Make sure the side rails (#5) are firmly in place. Attach the support legs (#8) to the center support (#7). Adjust the adjustable floor protector according to ground level.
- Page 6 Align slats (#6) to each end of the side rails (#5). Secure the slats (#6) to the side rails (#5) with screws (#E).
- Page 7 For more information contact our team: service.ec@foagroup.com...
- Page 10 Prepare 6 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align legs (#2R/L) to the holes in the back of the headboard (#1), then secure with bolts (#A) as shown in the picture. Prepare 2 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A).
- Page 11 Hook the side rails (#5) through the gaps of the headboard (#1) and footboard (#4). Make sure the side rails (#5) are firmly in place. Attach the support legs (#8) to the center support (#7). Adjust the adjustable floor protector according to ground level.
- Page 12 Align slats (#6) to each end of the side rails (#5). Secure the slats (#6) to the side rails (#5) with screws (#E). Prepare 10 bolts assembly by inserting lock washer (#G), then flat washer (#H) onto bolts (#F). Align side rail top panels (#9) to each end of the side rails (#5), then secure with bolts (#F).
