VERSION # 21-03-09
1 / 9
MODEL #
CM7260EK /CK
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Phillips Screwdriver
(Not Included)
3 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM7260EK
Summary of Contents for Furniture of America CM7260EK
- Page 1 MODEL # CM7260EK /CK Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Phillips Screwdriver (Not Included) 3 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 9...
- Page 5 CM7260EK /CK #1 1pc #2 2pcs #3 1pc #4 1pcs #5 2pcs Headboard leg Cross Bar Headboard ( L-R ) Support Footboard Footboard leg (L-R ) #6 2pcs #7 4 pcs #8 8pcs Bed Side Rails Slats Slats Surpport legs...
- Page 6 CM7260EK /CK is packed in 3 cases Disignation Part Hardware Carton #A x 10pcs #B x 10pcs Headboard Panel #C x 10pcs #D x 1pc CM7260EK /CK -HB Headboard leg ( L-R ) Cross Bar Support #A x 4pcs Footboard...
- Page 7 ASSEMBLY INSTRUCTIONS Align HB legs (#2R/L) to HB support (#3) and headboard (#1), then secure by using bolts (#A) with washers (#B,C). Part #1 x1pc Part #2 x2pcs Part #3 x1pc Hardware #A x12pcs Hardware #B x12pcs Hardware #C x12pcs Part #4 x1pc Part...
- Page 8 ASSEMBLY INSTRUCTIONS Align and attach side rails (#6) to the headboard (#1) and footboard (#4). For CK size bed frame For EK size bed frame P art #6 x2pcs Part #7 x1pc Part #8 x2pcs Attach support legs (#8) to the slats (#7).
- Page 9 ASSEMBLY INSTRUCTIONS Hardware #E x8pcs Align slats to the side rails, then secure by using screws (#E). 9 / 9...
