ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7263Q
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 6
(Included)
(Not Included)
Rev: 16-11-23
Advertisement
Related Manuals for Furniture of America CM7263Q
Summary of Contents for Furniture of America CM7263Q
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7263Q ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 8pcs Headboard Bolt Ø5/16" x 1-3/8" #B x 8pcs #2 x 2pcs Lock Washer Ø5/16"...
- Page 4 Prepare 6 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align legs (#2R/L) to the holes of the headboard (#1). Secure with bolts (#A). #A x 6pcs #B x 6pcs #C x 6pcs Prepare 2 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align leg support (#3) to the holes of the legs (#2R/L).
- Page 5 Hook the side rails (#5) to the latch of the headboard (#1) and footboard (#4). Make sure side rails (#5) are firmly hooked onto the headboard (#1) and foot board (#4). Attach support leg (#7) to each slats (#6). Adjust floor protector according to ground level.
- Page 6 Align slats (#6) to the side rails (#5), then secure with bolts (#E). #E x 8pcs ASSEMBLY IS COMPLETED Page 6 of 6...
