For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7298Q/F
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 7
(Included)
(Not Included)
Rev: 19-01-14
Advertisement
Related Manuals for Furniture of America CM7298Q/F
Summary of Contents for Furniture of America CM7298Q/F
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7298Q/F ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 7...
-
Page 3: Parts List
Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1pc #A x 6pcs Headboard Bolt Ø5/16" x 1-3/8" #2 x 2pcs #B x 6pcs Leg Headboard (L&R) Flat Washer Ø5/16"... -
Page 4: Exploded View
Exploded View Insert 2 metal dowels (#E) into the holes along the bottom of each end of the headboard (#1), then apply the legs (#2) onto those metal dowels (#E). #E x 4pcs Page 4 of 7... - Page 5 1. Prepare 6 bolt assemblies by inserting washer (#B,#G) onto the bolt (#A). #A x 6pcs #B x 6pcs #G x 6pcs 2. Insert 3 bolt assemblies into each leg (#2), then secure using the Allen wrench (#F). Insert 2 screws (#D) into the holes along the inner side of the legs (#2), then secure using a screwdriver.
- Page 6 Hook each end of the side rails (#4) onto the slots along the headboard (#1) and footboard (#3). Insert the threaded end of the center support legs (#7) into the holes along the center rail (#5). Turn right tighten. Leveler Adjust leveler according to ground level.
- Page 7 Place the slats (#6) onto the side rails (#4), then insert a screw (#C) into each end. Secure using a Phillips screwdriver. #C x 18pcs Insert a total of 3 screws (#C) into the center of the slats (#6). #C x 3pcs Page 7 of 7...
