VERSION
# 20-03-16
1 / 9
MODEL #
CM7277EK/CK
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
Wrench
(Included)
3 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM7277EK
Summary of Contents for Furniture of America CM7277EK
- Page 1 MODEL # CM7277EK/CK Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Phillips Screwdriver (Not Included) Wrench (Included) 3 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 9...
- Page 5 E.KING BED CAL.KING BED CM7277EK/CK #4 2pcs #1 1pc #3 1pc #2 1pc Side Rail Footboard Headboard #6 8pcs #5 4pcs Support Leg 235*30*30mm Slat #A 4pcs #B 4pcs #C 4pcs #D 1pc Bolt Ø5/16" x 1-3/4" Lock washer Flat washer Allen wrench 5mm Ø5/16"...
- Page 6 CM7277EK/CK is packed in 3 cases Carton Hardware Disignation Part #A 4pcs Headboard #B 4pcs CM7277EK/CK- HB #C 4pcs #D 1pc CM7277EK/CK- FB Footboard #E 8pcs Side Rail #F 8pcs #G 1pc #H 8pcs Slat CM7277EK/CK-R Support Leg 6 / 9...
-
Page 7: Exploded View
EXPLODED VIEW 7 / 9... - Page 8 ASSEMBLY INSTRUCTIONS Align HB leg rail (#2) to the headboard (#1), then secure by using bolts (#A) with washers (#B,C). Part #1 x1pc Part #2 x1pc Hardware #A x4pcs Hardware #B x4pcs Hardware #C x4pcs Part #3 x1pc Part #4 x2pcs Hardware #E x8pcs Hardware...
- Page 9 ASSEMBLY INSTRUCTIONS Part Attach support legs (#6) to the slats (#5). Adjust #5 x4pcs Part the leveler on the support legs (#6) according to #6 x8pcs ground level. Align slats to the side rails, then Hardware #H x8pcs secure by using screws (#H). 9 / 9...
