RGBlink Q2 Quick Start Manual page 8

Purple Input slots 1-9,supporting DVI,HDMI,
Input 1-9 DP,H.264 modules
Yellow
Communication board with LAN port，
COMM to connect router or computer to
realize software control
Dual Power(for 4U and above)
© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: +86 592 5771197 |
support@rgblink.com
Q2-4
Blue Output slots 1-5, supporting HDMI,DVI
Input 1-5 modules
RS232 serial port for Open API command
|
www.rgblink.com
