5. AIS OPERATION
5.2

AIS Symbols

When the AIS is turned on, AIS targets are displayed with AIS symbol as below.
Target type
Sleeping target
Activated target
Dangerous target
Lost target
Selected target
Aid to navigation
(AtoN)
AIS base station
SART aircraft
AIS-SART
AIS Search and Res-
cue (SAR) Vessel
5-2
Symbol
Sleeping target
Activated target. Heading line and ROT are shown.
Ground tracking speed and course are shown with
vector.
A target whose distance, CPA and TCPA are less
than corresponding alarm settings.
A target for which no data has been received within
a certain period.The symbol flashes.
A target selected to show its target data.
(Physical)
(Virtual)
Always shown on the screen.
BS
Always shown on the screen.
Always shown on the screen.
A target for AIS search and rescue vessel.
Description
