AZUD HELIX AUTOMATIC 201 DLP User Manual page 3

INDEX
1. INTRODUCTION
2. FEATURES OF THE FILTRATION EQUIPMENT
2.1 Exclusive use of the Filtration Equipment.
2.2 Identification of the Product.
2.3 Operation Description.
2.4 Components and Spares.
2.5 Backflushing Valves.
3. TECHNICAL DATA
3.1 AZUD HELIX AUTOMATIC General Features and requirements. Serie 201.
3.2 Dimensions.
3.3 Azud Helix Automatic Filter.
4. SECURITY INFORMATION
5. INSTALLATION INSTRUCTIONS
5.1. Separation of the Equipment from the pallet.
5.2 Adjustment of the supports of the Equipment
5.3 Fastening the equipment to the floor.
5.4 Connection of the equipment.
5.5 Neumatic connection of the equipment and the Control Unit.
6. OPERATION INSTRUCTIONS
6.1 Start-up AZUD HELIX AUTOMATIC equipment.
6.2 Opening and closure of AZUD filters.
7. MAINTENANCE INSTRUCTIONS.
7.1 Maintenance Chart.
7.2. General inspection of the Equipment
7.3 Inspection of the filters
7.3.1 Cleaning of discs
7.3.2 Inspection of the gaskets.
7.3.3 Inspection of the movable elements of the base of the filtering element.
7.3.4 Inspection of the Piston elements
7.4 Inspection of the components.
7.4.1 ¾" Auxiliary Filter inspection.
7.4.2 ¼" Intake filter inspection.
7.4.3 Grooved couplings maintenance.
8. POSSIBLE PROBLEMS – CAUSES – SOLUTIONS.
9. WARRANTY.
Water Filtration Solutions
4
4
9
11
12
15
16
21
24
