5 –Assemble the equipment in the installation, connecting the inlet, outlet and drainage manifolds
using their corresponding
6 – Install a glycerin pressure gauge (0-10) bar to measure the pressure coming into the valve. It is
recommended to use liquid sealing or LOCTITE 5331, but not in excess.
7 –Place the 2" BSP Cap in the free outlet of the filter base. Said cap does not need sealing
because it is provided with an o-ring.
8 –Place the cartridge in the filter base. After this, place the lid on it and close it with the clamp.
9 –Check the correct connection of the equipment and fix the shoulders to the ground in order to
avoid vibrations.
To CLOSE the filters, check there are not strange elements in the area of the O-ring of the base and
the state of the same. Place carefully the lid and close the filter with the clamp. To close the clamp,
place the bolt in its emplacement and adjust the lever, place the anti-opening device and thread the
safety screw without force it.
- Pressure equipment: Make sure that the filter is depressurized before opening it.
- For the Equipment's operation, use the adequate personal protection (adequate
clothes, protective glasses, gloves and other elements of personal protection ...).
- Do not forget to adjust the safety lock of the clamp. It will avoid its accidental
opening.
- It is recommended the installation of an upstream and downstream valve to isolate
the system during maintenance operations.
