COMGROW CNC Carving Machine User Manual page 9

Install Driver & Software
1. Install the driver
1.If you are using it for the first time,
you need to perform steps 1-9 to Install
the driver.Firstly ,Insert the complimentary
SD card into your computer via USB.
2.Open the SD card, select
"CNC Carving Machine".
3.Select "software".
4.Select "win".If you're on ios,
choose "mac".
5.Select "Driver".
6.Double click "CH340SER".
7.Click "INSTALL",start installing drivers.
8.Click "OK" , finish Install the driver.
14
2. To Determine your Machine's COM port:
•
Windows XP: Right click on "My Computer", select "Manage", select "Device Manager".
•
Windows 7: Click "Start" Right click "Computer" Select "Manage" Select "Device Manager"
from left panel.
•
In the tree, expand "Ports (COM & LPT)"
•
Your machine will be the USB Serial Port (COMX), where the "X" represents the COM number,
for example COM12.
•
If there are multiple USB serial ports, right click each one and check the manufacturer,
the machine will be "CH340".
15
