COMGROW CNC Carving Machine User Manual page 5

Assembly：Part 2
Ready:
e：back side panel（x1）
f：M5X12 Screw（x2）
06
(e)
(f)
Use two M5*12 screws (f) to secure the back side panel (e)
to the rear of the Y-axis base
Assembly：Part 3
Ready:
(h)
g：M5X12 Screw（x6）
(g)
Using six M5*12 screws (g) ,
secure the XZ-axis gantry (h)
to the side of the Y-axis base.
h：XZ-axis gantry（x1）
07
