COMGROW CNC Carving Machine User Manual page 14

Offline Controller
Notice: If you want to run the CNC machine with an offline controller, you must first disconnect the USB cable
from the controller board.
1. Connect the memory card to the computer through a card reader, copy the G-code into the memory
card, and then insert the memory card into the offline control handle.
2. Connect the offline controller to the control motherboard.
3. Press the [X+/X-/Y+/Y-/Z+/Z-] key to move the spindle to the machine origin, select the engraving file,
click the [OK] key to start engraving.
4. Interface introduction
A. Off-line controller button
OK
BACK
RESET
X-/X+/Y-/Y+/Z-/Z+
24
Confirmation
Return to previous page
Reset system
Control X/Y/Z axis move
B. Menu Page
Move
File Return to previous page
SSet
Laser/SPN:100%
(Press [Z+]=add or press [Z-]=reduce)
Press key [X-] or [X+] to select
Press key [OK] to Enter
Press key [RESET] to reset system
Confirmation
Reset system
Power to spindle
25
