COMGROW CNC Carving Machine User Manual page 16

Laser engraving
Our machine can be used to do CNC engraving or laser engraving. To use laser engraving, you need to
install the LaserGRBL Control Software first.
1.If you are using it for the first time,
you need to install the software.
Open the SD card,select "LaserGRBL
Control Software".
2.Select "install.exe".start the installation .
3.Select an installation path and then
click the"Next" .
4.Click the"Next".
5.Click the"Install", start the installation .
6.Click the"Finish" to complete the installation
and open it .
28
7.When you open the software,click the
"Connect" to connect the CNC machine
8.Click "Open File" and select
the engraving file.
9.Enter the command "$32=1" on the
computer side to turn on the laser engraving
mode,and then the spindle rotation mode is
turned off.
10.Enter "$32=0" at the computer side to
turn off the laser engraving mode, and then
switch the spindle engraving mode .
29
