Region: Global REV1.0
USER MANUAL
Open Energy for All
HYT-5.0HV-EUG1
HYT-6.0HV-EUG1
HYT-8.0HV-EUG1
HYT-10.0HV-EUG1
HYT-12.0HV-EUG1
hoymiles.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HYT-5.0HV-EUG1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hoymiles HYT-5.0HV-EUG1

Summary of Contents for Hoymiles HYT-5.0HV-EUG1

  • Page 1 Open Energy for All USER MANUAL HYT-5.0HV-EUG1 HYT-6.0HV-EUG1 HYT-8.0HV-EUG1 HYT-10.0HV-EUG1 HYT-12.0HV-EUG1 Region: Global REV1.0 hoymiles.com...

  • Page 2: Table Of Contents

    3.3.5.2 Smart Meter and CT Connection 3.3.5.3 DRM Connection 3.3.5.4 DI Connection 3.3.5.5 DO Connection 3.3.5.6 Parallel Connection 3.3.6 DTS Connection 3.4 Operation 3.4.1 S-Miles Cloud APP 3.4.2 Commissioning 3.4.3 Decommissioning Troubleshooting Technical Datasheet Contact Information © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 3: Safety Introduction

    Burn danger due to hot surface that may exceed 60℃. Refer to the operating instructions. Wait for at least 10 minutes before opening the inverter or touching live parts. 10min Products shall not be disposed as household waste. CE mark. © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 4: Safety Information

    Safety instructions in this manual cannot cover all precautions that should be taken. Please consider the actual conditions on site when performing operations. Any damage caused by a violation of the safety instructions in this manual shall not be the responsibility of Hoymiles. Symbol...
  • Page 5 Please keep the user manual properly. • The manual contains no user-serviceable parts. See Warranty for instructions on obtaining service. • If an error occurs, refer to troubleshooting or contact your local distributor or qualified electricians. © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 6: Introduction

    Prior to any electrical connections, keep in mind that the inverter has dual power supplies. It is mandatory for the qualified personnel to wear personal protective equipment (PPE) during the electrical work. WARNING © 2022 Hoymiles Power Electronics Inc. All rights reserved.
  • Page 7 On – BMS and meter communications are OK Off – No fault On - A fault happens Blink 1 – EPS port overload FAULT Blink 2 – ISO/RCD fault Blink 3 – Arc fault © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 8: Operating Modes

    PV surplus power selling Consuming from grid Battery discharging Loads Battery charging at night Self consuming (PV power generation) 24:00 00:00 discharging standby charging standby discharging Power flow of self-consumption mode © 2022 Hoymiles Power Electronics Inc. All rights reserved.
  • Page 9 In case of frequent power outages, a backup power SOC can be Back-up Mode configured, which ensures that the battery always has enough energy to handle critical loads. Power flow of back-up mode © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 10: System Diagram

    This diagram is a simplified system sketch that is only intended to explain system architecture. • Please refer to https://www.hoymiles.com for compatible battery list, user should first contact Hoymiles for technical consultation and obtain NOTICE official confirmation prior to installing any battery not included in the official published list.

  • Page 11: Basic Diagram

    If battery integrates a readily accessible internal DC breaker, no additional ① DC breaker is required. ⑥⑦ 30mA RCD is recommended not mandatory, please comply with local regulation, please comply with local regulation. © 2022 Hoymiles Power Electronics Inc. All rights reserved.
  • Page 12 If battery integrates a readily accessible internal DC breaker, no additional ① DC breaker is required. ⑥⑦ 30mA RCD is recommended not mandatory, please comply with local regulation, please comply with local regulation. © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 13: Retrofit System

    The detailed wiring of your system depends on the requirements you have. Please consult your system integrator for more information. 2.3.3 Unacceptable Diagram Avoid the following installation types to prevent damage to the system or the inverter. © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 14: Installation Instruction

    Hybrid Inverter User Manual 3. Installation Instruction Packing List Please ensure that none of the components listed below are missing or damaged upon receipt of the hybrid inverter. © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 15: Mounting

    6. The inverter should be installed at eye level for convenient maintenance. 7. The product label on the inverter should be clearly visible after installation. 8. The inverter should be installed far from flammable materials. © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 16: Mounting Inverter

    Procedure Prepare the cable and OT/DT Step 1 terminal. L=H+(2-3)mm Step 2 Use the screw from the mm² accessory box. Then fasten the cable with a screwdriver. 1.2 N·m © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 17: Pv Wiring Connection

    1,000V • Connect the PV connectors to the inverter. There should be a “click” if it is plugged in Click correctly. © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 18: Battery Wiring Connection

    For batteries without a built-in DC breaker, make sure that an external DC breaker is connected. If you need to use this hybrid inverter as a grid-tied inverter, please contact Hoymiles for help. •...

  • Page 19: Ac Wiring Connection

    Assemble the parts in sequence. Step 5 • Tighten the waterproof terminal clockwise • Connect the grid connector to the inverter. There should be a “click” sound, if it is plugged in correctly. Click © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 20: Eps Connection

    Step 2 counterclockwise. • Disassemble the parts in sequence. • Press the connectors tightly on the Step 3 cable conductor core. Make sure the cable jacket is not locked within the connector. © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 21: Communication Wiring Connection

    Dry-contact output. The DO2 can be set to one of the DO2 (NO2, COM2) functions as follows: Earth Fault Alarm, Load Control, Backup Load Smart Control and Generator Control. © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 22: Bms Connection

    • Clip the ethernet cable into the rubber ring. Step 5 • Insert the RJ45 plug into the front plug connector until it clicks. • Tighten the cable gland. © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 23: Smart Meter And Ct Connection

    • Connect grid L1/L2/L3/N to meter’s terminals 3/6/9/10. • Clamp three CTs to L1/L2/L3/N and connect wirings to 13/14, 16/17, and 19/21 Respectively. Step 2 • Connect the communication cable between the inverter and smart meter. 485A 485B © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 24: Drm Connection

    • Clip the cable into the Rubber ring. Step 5 • Plug the wires into the terminal block firmly according following tables. 4 6 8 © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 25: Di Connection

    The inverter has integrated a multiple-function dry-contact (DO1 and DO2). The DO1 can control the external bypass contactor if used, for more information please contact Hoymiles technical support team. The DO2 can be set to one of the functions as follows, Earth Fault Alarm, Load Control, and Generator Control.

  • Page 26: Parallel Connection

    Hybrid Inverter User Manual 3.3.5.6 Parallel Connection The parallel function is in developing and could be realized through OTA. For more information, please contact Hoymiles technical support team. 3.3.6 DTS Connection DTS-WIFI-G1 and DTS-4G-G1 Procedure Steps • Remove the DTS port cover plate.

  • Page 27: Operation

    BLINK Improper communication with Cloud, but the network is connected. 3.4 Operation 3.4.1 S-Miles Cloud Application The S-Miles Cloud application has been developed for Hoymiles' hybrid inverter and offers the following features, a. Network configuration; b. Local installation assistant; c. System monitoring;...

  • Page 28: Commissioning

    Step 6 Disconnect all the communication cables. Remove DTS and power meter. Remove the inverter from the wall, and remove the bracket if necessary. Step 7 Pack the inverter and accessories. © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 29: Troubleshooting

    3. Check whether the cross-sectional area of the AC cable meets the requirement. 4. If the alarm persists, contact Hoymiles technical support team. Generally, the inverter will reconnect to the grid after the grid recovers. If the alarm occurs frequently: 1.
  • Page 30 Meter Reverse The inverter detects that the Meter instructions from User Manual. Connection or CT is reverse connected. 2. If the alarm persists, please contact Hoymiles technical support team. 1. Check whether the Meter communication cable and Meter terminal are abnormal.
  • Page 31 BMS. battery manufacturer. The inverter detects that there Try to restart the inverter. If the fault persists, Relay Fault is a relay self-check fault. contact Hoymiles technical support team. © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 32: Technical Datasheet

    16000, 10s 16000, 10s 16000, 10s Nominal AC Voltage (V) 400/380, 3L/N/PE Nominal AC Frequency (Hz) 50/60 Max. Output Current (A) 10.0 13.3 16.7 17.4 Total Harmonic Distortion <3% (@linear load) © 2022 Hoymiles Power Electronics Inc. All rights reserved.
  • Page 33 DRM, 1 × DI, 2 × DO Isolation Method (Solar/Battery) Transformerless / Transformerless Certifications and Standards Grid Regulation EN 50549, VDE-AR-N 4105, AS/NZS 4777.2 Safety Regulation IEC 62109-1, IEC 62109-2 EN 61000-6-1, EN 61000-6-3 © 2022 Hoymiles Power Electronics Inc. All rights reserved.

  • Page 34: Contact Information

    Hybrid Inverter User Manual 6. Contact Information S-Miles Installer S-Miles Enduser China No.18 Kangjing Road, Hangzhou, China +86 571 2805 6101 General inquiry: info@hoymiles.com Technical support: service@hoymiles.com Visit https://www.hoymiles.com/ for more informations. © 2022 Hoymiles Power Electronics Inc. All rights reserved.

This manual is also suitable for:

Hyt-6.0hv-eug1Hyt-8.0hv-eug1Hyt-10.0hv-eug1Hyt-12.0hv-eug1
