TVT TD-6424M3 Quick Start Manual

Panoramic Bullet
Network Camera
Quick Start Guide
■ Please read this instruction carefully before using the product
and keep it for further reference.
■ All the examples and pictures used here are for reference only.
■ The contents of this manual are subject to change without
notice.
1
Warning and Caution
■ If the product does not work properly, please contact your dealer
or the nearest service center. Never attempt to disassemble the
camera yourself. (We shall not be responsible for any problems
caused by unauthorized repair or maintenance.)
■ Do not allow water or liquid intrusion into the camera.
■ In the use of the product, you must be strict compliance with the
electrical safety regulations of the nation and region. When the
product is mounted on wall or ceiling, the device shall be firmly
fixed.
■ Do not use camera beyond specified voltage range.
■ Do not drop the camera or subject it to physical shock.
■ The grounding hole of the product is recommended to be
grounded to further enhance the reliability of the camera.
■ Avoid touching the camera lens.
■ If cleaning is necessary, please use clean cloth to wipe it gently.
■ Do not aim the camera at the sun or extra bright place.
■ Do not place the camera in extremely hot, cold, dusty or damp
locations, and do not expose it to high electromagnetic radiation.
■ To avoid heat accumulation, good ventilation is required for
operating environment.
2
Package
Camera Quick start guide
CD Drill template
Screwdriver Rubber plug
3
Overview
1
2
3
4
5
8 9
6
7
8
9 Micro SD Card Slot
* 1
It is recommended to install the security cap for outdoor installation.
* 2 This camera can be powered by DC 12V/PoE power supply. If the PoE switch
is used to power the camera, DC12V power supply is not required.
4 tapping screws
Plastic plug ×4
●
Connecting Alarm Input/Output
Alarm Input
IPC
Alarm Output
1
2
●
Connecting Network Cable
3
4
5
6
7
1
Ethernet Connector *
Audio Input (MIC)
① Loosen the nut from the main element.
Audio Output (HP)
② Run the network cable (without RJ 45 connector) through the
Alarm Input/Output
both elements. Then crimp the cable with RJ 45 connector.
RS485
③ Connect the cable to the E
Power Connector *
nut and the main cover.
Ground
Reset
4
Installation
Please make sure that the wall or ceiling is strong enough to
withstand 3 times the weight of the camera.
① Open the cover of the camera and then insert a micro SD card.
Then install back this cover and fix it firmly with the screws (please
keep it flat when installing).
1--ALM-COM
2--ALM-OPEN
3--ALM-INA
4--ALM-GND
RS485T+
RS485T-
ALARM-INA
3
Sensor
ALARM-GND 4
+
ALARM-COM 1
IPC
-
+
-
ALARM-OPEN 2
Power Source
2
thernet connector. Then tighten the
Alarm
