Intermec IV7 Supplementary Manual

Using This Template

Use this template if you need to drill holes in a mounting surface when installing
the IV7 Vehicle-Mount Reader. For more information on installing the IV7, see the
IV7 Vehicle-Mount Reader Instructions (P/N 075280).
0.71 cm
(0.28 in)
1.02 cm
(0.40 in)
0.71 cm
(0.28 in)
6001 36th Avenue West
Everett, Washington 98203
U.S.A.
tel 425.348.2600
fax 425.355.9551
www.intermec.com
©
2005 Intermec Technologies
Corporation. All rights reserved.
IV7 Vehicle-Mount Reader Drilling Template
*931-000-001*
P/N 931-000-001 Rev A
30.81 cm
(12.13 in)
30.48 cm
(12.00 in)

Scale 1:1

Reproductions or copies
may not be to scale.
IV7 Vehicle-Mount Reader Drilling Template
5.08 cm
(2.00 in)
