- Page 1 Installation Guide Forklift RFID System (IV7 and Antennas)
- Page 2 Information and specifications contained in this document are subject to change without prior noticed and do not represent a commitment on the part of Intermec Technologies Corporation. © 2006 by Intermec Technologies Corporation. All rights reserved. Forklift RFID System Installation Guide...
-
Page 3: Table Of Contents
Before You Begin........v Safety Information ......v Global Services and Support . - Page 4 Forklift RFID System Installation Guide...
-
Page 5: Before You Begin
Your safety is extremely important. Read and follow all warnings and cautions in this document before handling and operating Intermec equipment. You can be seriously injured, and equipment and data can be damaged if you do not follow the safety warnings and cautions. -
Page 6: Global Services And Support
Global Services and Support Warranty Information To understand the warranty for your Intermec product, visit the Intermec web site at www.intermec.com Support > Warranty. Disclaimer of warranties: The sample code included in this document is presented for reference only. The code does not necessarily represent complete, tested programs. -
Page 7: Who Should Read This Manual
IV7 and its antennas on a forklift load backrest. Before you begin this installation, you should be familiar with Intermec RFID products and basic RFID system terminology. Related Documents This table contains a list of related Intermec documents and their part numbers. Document Title IV7 Vehicle-Mount Reader Instructions... - Page 8 2 Click Service & Support > Manuals. 3 In the Select a Product field, choose the product whose documentation you want to download. To order printed versions of the Intermec manuals, contact your local Intermec representative or distributor. viii www.intermec.com...
-
Page 9: What Is A Forklift Rfid System
Components of a Typical Forklift RFID System • Intermec Vehicle-Mount Computer. For example, a CV60 or a CV30. • Intermec IV7 Vehicle-Mount RFID Reader with these cables: •... -
Page 10: Safety Information
Corrugated wire loom, slit, 0.250 ID Forklift RFID System Installation Guide Safety Information Before you install any Intermec products on the forklift, contact the forklift manufacturer or your vehicle maintenance company to correctly identify the appropriate power connections for the products. -
Page 11: Before You Install The Forklift Rfid System
Before you begin this installation, you should be familiar with Intermec RFID products and basic RFID system terminology. For help, see the Intermec RFID System Manual (P/N 936-000- xxx). Installing the Forklift RFID System Consult the vehicle manufacturer or your vehicle... -
Page 12: Installing The Iv7
4 Install the RFID antennas on the forklift load backrest. For help using the installation kit, see “Installing the Antennas” on page 14. For testing purposes, you can temporarily mount the antennas until you find the best locations for permanent mounting. - Page 13 U-bolt (4 places) Installing an IV7: This illustration provides an example of how you can install the IV7 to the forklift load backrest. To install the IV7 1 Study the previous illustration. 2 Attach the top of the IV7 to one of the mounting straps (18.0 in).
-
Page 14: Installing The Antennas
5 Attach the bottom of the IV7 to the mounting strap you secured in Step 4. 6 Attach caps to the ends of all U-bolts. You can use either the smaller caps (if the ends are exposed) or the larger caps (if you also need to cover the hex nut). -
Page 15: Completing The Installation
3 Use two U-bolts to secure the mounting strap to the load backrest. Mount the antenna so that it faces the forks (where the RFID tags will be). Note: You may need to use extra hex nuts on the U-bolts to ensure that the antenna does not extend into the area where a pallet or container could damage 4 To install the other antenna, repeat Step 2 and Step 3. -
Page 16: Mounting On The Forklift Load Backrest
Once you have figured out the best potential locations for the antennas, you need to mount the antennas on the forklift. Exactly how you mount the antennas depends on many factors, including: • forklift configuration. Is there space between the spines on the load backrest for mounting an antenna? Is it okay to remove one of the spines to accommodate mounting an antenna? •... -
Page 17: Mounting Between The Forks
You may need to modify the load backrest to protect the antenna from load impact damage. Ideally, the antenna should be recessed in a metal frame. Mounting Between the Forks If the application is designed to read pallet tags placed on the bottom of pallets or other containers, you may want to mount the antenns between the forks. - Page 18 Forklift RFID System Installation Guide...
- Page 20 Worldwide Headquarters 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com Forklift RFID System Installation Guide *075412-001* P/N 075412-001...
