DEMO MANUAL DC2072A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 1 C2
2 2 C3, C4
3 1 C5
4 1 C6
5 1 C7
6 2 R1, R9
7 1 R2
8 1 R3
9 1 R4
10 1 R5
11 1 R6
12 1 R7
13 1 R10
14 1 R12
15 1 U1
Additional Demo Board Circuit Components
1 1 C1
2 0 R8, R11 (OPT)
Hardware: For Demo Board Only
1 6 E1-E6
2 1 JP1
3 1 JP2
4 2 XJP1, XJP2
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP., X7R, 10µF, 50V, 10% 1210
CAP., X7R, 4.7µF, 50V, 10% 1210
CAP., X7R, 0.01µF, 16V, 20% 0603
CAP., X7R, 1nF, 16V, 20% 0603
CAP., X7R, 0.022µF,16V, 20% 0402
RES., CHIP, 60.4k, 0.06W, 1% 0402
RES., CHIP, 90.9k, 0.06W, 1% 0402
RES., CHIP, 121k, 0.06W, 1% 0402
RES., CHIP, 140k, 0.06W, 1% 0402
RES., CHIP, 191k, 0.06W, 1% 0402
RES., CHIP, 274k, 0.06W, 1% 0402
RES., CHIP, 442k, 0.06W, 1% 0402
RES., CHIP, 604Ω, 0.06W, 1% 0603
RES., CHIP, 499k, 0.06W, 1% 0603
I.C., MICROPOWER LDO DFN-10-3X3
CAP., ALUM., 22µF, 50V, CE-BSS SERIES
RES., 0603
TESTPOINT, TURRET, .094" PBF
HEADERS, 2 × 8 (2mm Ctrs.)
HEADERS, 3 PINS 2mm Ctrs.
SHUNT, .079" CENTER
MANUFACTURER/PART NUMBER
MURATA, GRM32ER71H106KA12L
MURATA, GRM32ER71H475KA88L
AVX, 0603YC103MAT2A
AVX, 0603YC102MAT2A
AVX, 0402YC223KMAT2A
VISHAY, CRCW040260K4FKED
VISHAY, CRCW040290K9FKED
VISHAY, CRCW0402121KFKED
VISHAY, CRCW0402140KFKED
VISHAY, CRCW0402191KFKED
VISHAY, CRCW0402274KFKED
VISHAY, CRCW0402442KFKED
VISHAY, CRCW0603604RFKEA
VISHAY, CRCW0603499KFKEA
LINEAR TECH., LT3065EDD
SUN SELECT., 50CE22BSS
MILL-MAX, 2501-2-00-80-00-00-07-0
SAMTEC, TMM-108-02-L-D
SULLINS, NRPN031PAEN-RC
SAMTEC, 2SN-BK-G
