CAUTION: You must read this before you proceed
Please look in the Seat Panel for hardware packs
Caution: This Double Sunlounge is NOT a TOY.
Keep your child/children at bay during the assembly process.
Whenever lifting or moving the Double Sunlounge and to prevent injury to
yourself or damage to the Double Sunlounge, two adults are needed to
execute these actions.
Noble House Home Furnishings LLC
DOUBLE SUNLOUNGER
.
1 of 9
Advertisement
Related Manuals for Noble House Home Furnishings DOUBLE SUNLOUNGER
Summary of Contents for Noble House Home Furnishings DOUBLE SUNLOUNGER
- Page 1 Keep your child/children at bay during the assembly process. Whenever lifting or moving the Double Sunlounge and to prevent injury to yourself or damage to the Double Sunlounge, two adults are needed to execute these actions. Noble House Home Furnishings LLC 1 of 9...
- Page 2 Picture Description Label Foldable Seat Panel Left Leg Panel with Wooden Bar Right Leg Panel with Wooden Bar Front Leg Panel Wheel Leg Support Bar Foldable Cushion Noble House Home Furnishings LLC 2 of 9...
- Page 3 Picture Description Allen Wrench Bolt (M6*35mm) Bolt (M6*70mm Sleeve Nut (M6*15mm) Bolt for Wheel (M8*55mm) Iron tube for Wheel (8*8*23) Washer (8*20*2) Sleeve Nut (M8*15mm) Screw (M7*60mm) Noble House Home Furnishings LLC 3 of 9...
- Page 4 To give you an overview of the Double Sunlounge parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly. Noble House Home Furnishings LLC 4 of 9...
- Page 5 )with Allen Wrench (1) 3.3)Unfold the pre-fixed Middle Leg as shown in above picture and secure it to FoldableSeat Panel(A) using Bolt( )with Allen Wrench ( 1 ). Do not fully tighten the Bolts. Noble House Home Furnishings LLC 5 of 9...
- Page 6 Allen Wrench ( 1 ) as shown on above picture. 5.2) Attach Leg Support Bar(F) to Left Leg Panel(B) using Screw(9) with Allen Wrench (1 ). Do not fully tighten Bolts and Screw. Noble House Home Furnishings LLC 6 of 9...
- Page 7 Attach Wheels(E) to Left Leg Panel(B) and Right Leg Panel(C) using Bolt for Wheel( 5 ), Washers( 7 ), Iron Tube for Wheel( 6 ) and Sleeve Nut( 8 ) in the sequence in the above. Do not fully tighten Bolts Noble House Home Furnishings LLC 7 of 9...
- Page 8 Tie magic tape straps on Foldable Seat Cushion(G) to Foldable Seat Panel(A) as shown above. Your Double Sunlounge is ready for use. This Double Sunlounge can only be used on a flat, level surface. Note: Align the Backrest of Sunlounge in position you want. Noble House Home Furnishings LLC 8 of 9...
- Page 9 Not for commercial use. For residential use only . Stains may be removed with mild soap solution and damp cloth. M D ABCDEG Dust and pick-up spills using a clean, non colored lint-free cloth Noble House Home Furnishings LLC 9 of 9...
