Assembly Instructions
Caution: You must read this before you proceed
Chair
Note: This Chair is NOT a TOY.
Keep your child/children at bay during the assembly process.
The Chair is HEAVY.
To prevent injury to yourself or damage to the product a minimum of
two adults are required whenever moving or lifting it.
Noble House Home Furnishings LLC
Page 1 of 7
Advertisement
Table of Contents
Related Manuals for Noble House Home Furnishings Chair
Summary of Contents for Noble House Home Furnishings Chair
- Page 1 Assembly Instructions Caution: You must read this before you proceed Chair Note: This Chair is NOT a TOY. Keep your child/children at bay during the assembly process. The Chair is HEAVY. To prevent injury to yourself or damage to the product a minimum of two adults are required whenever moving or lifting it.
- Page 2 Picture Description Right Arm Panel Left Arm Panel Backrest Panel Seat Panel Back Cushion Seat Cushion Hardware Label Picture Description Bolt ④ (M6x 35 mm) Screw ⑤ (M6x80mm) ⑥ Allen Key Noble House Home Furnishings LLC Page 2 of 7...
- Page 3 FRONT FACING Seat Cushion (L) This Chair has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Chair parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
- Page 4 3.1) Attach Right Arm Panel(G) to Backrest Panel(I) using Bolts(④) with Allen Key(⑥). 3.2) Attach Right Arm Panel(G) to Seat Panel(J) using Bolts(④) with Allen Key(⑥). Do not fully tigthen the Bolts. Noble House Home Furnishings LLC Page 4 of 7...
- Page 5 Stand the Chair up, with assistance from your adult partner. Exert pressure floorwards, onto the Chair with both your hands. This pressure will help the Legs and Chair reach full alignment status. Check for wobbles on a LEVEL surface. If no wobbles are found proceed to tighten Bolts and Screws in a sequential manner, until evenly secured.
- Page 6 Step 6 Inspect the Chair and make sure all parts are connected. Place Seat Cushion(L) and Back Cushion(K) onto the Chair as shown picture. Tie the velcro straps of Back Cushion(K) and Seat Cushion(F) to Backrest Panel(I) and Seat Panel(J) as pictured.
- Page 7 Noble House Home Furnishings LLC Page 7 of 7...
