Assembly Instructions
Caution: You must read this before you proceed
Bench
Caution: This Bench is NOT a TOY
Keep your child/children at bay during the assembly process.
Whenever moving/lifting the Bench and to prevent damage to the Bench, two adults are needed
to execute these actions.
Parts List
Label
Description
QTY
A
Bench Seat Panel
1
Noble House Home Furnishings LLC
Page 1 of 7
Advertisement
Table of Contents
Related Manuals for Noble House Home Furnishings Bench
Summary of Contents for Noble House Home Furnishings Bench
- Page 1 Caution: You must read this before you proceed Bench Caution: This Bench is NOT a TOY Keep your child/children at bay during the assembly process. Whenever moving/lifting the Bench and to prevent damage to the Bench, two adults are needed to execute these actions. Parts List Label...
- Page 2 Iron Leg Frame Leg Support Bar Hardware Label Picture Description Bolt ① (M6x20mm) ② Washer Screw ③ (M6x45mm) ④ Allen Key Noble House Home Furnishings LLC Page 2 of 7...
- Page 3 Assembly Preparation Before Beginning Assembly: Noble House Home Furnishings LLC Page 3 of 7...
- Page 4 FRONT FACING This Bench has multiple parts and may require up to 15 minutes to assemble. To give you an overview of the Bench parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
- Page 5 Step 2 Position Bench Seat Panel(A) facedown on a clean, non-marring surface. Attach Iron Leg Frames(B) to Bench Seat Panel(A) using Bolts(①), and Washers(②) with Allen Key(④). Do not fully tighten the Bolts. Step 3 Iron Dowel Insert the Leg Support Bar(C) with pre-fixed iron dowels into the housings on Iron Leg Frames(B) as pictured.
- Page 6 Step 4 Attach the Iron Leg Frames(B) to the Bench Seat Panel(A) using Screws(③) with Allen Key(④). Do not fully tighten the Screws. Step 5 Adjust Pre-installed Levellers height for balance Noble House Home Furnishings LLC Page 6 of 7...
- Page 7 Inspect it and make sure all parts are adequately connected. Gently and gracefully, sit onto the Bench. This pressure will help the Legs and Bench reach full alignment status. Check for wobbles on a LEVEL surface. If no wobbles are found proceed to tighten the Bolts and Screws in a sequential manner, until evenly secured.
